Leviton GigaMax™ 5e Universal Patch Panels

LE-5G596-U96
Qty:

What's special about these patch panels from Leviton?

  • Meets or exceeds Category 5e requirements in TIA/EIA-568-B and Class E requirements in ISO/IEC 11801-B.
  • Panels contain both Universal T568A and T568B Wiring Configurations White IDC 110 punch down modules.
  • Color-coded front window labeling for easy port identification.
  • Termination standoff for optional grounding
  • Panels have a universal T568A and T568B wiring card for 110 style IDC Terminations
  • Mounts on a standard 19" equipment rack
  • Click for More Features
    •
  • ULFCC

Leviton GigaMax™ 5e Patch Panels and patch blocks are one of the most popular patch panel systems for providing outstanding Category 5e performance with user friendly features. It is an easy-to-install panel for any modular cross connect system with 110 punch downs in the rear of the panel with six port RJ-45 modules on the front. Available in 12, 24, 48, and 96 port configurations, and 12-port patch block. These patch panels are UL certified, and meet or exceed all TIA/EIA-568-B for Category 5e requirements and meets FCC Part 68.

Part # Description Dimensions Weight Price
LE-5G596-U96 96 Port GigaMax 5e Universal Patch Panel 7.0" H x 19" W x 1.31" D 6.2 lbs
Qty:
Manufacturer Direct
LE-5G596-U89 12 Port GigaMax 5e Universal U89 Patch Block
with Mounting Bracket for Wall Mounting		 10.0" H x 2.3 " W x 1.474" D 1.1 lbs
Qty:
Manufacturer Direct
  • Meets or exceeds Category 5e requirements in TIA/EIA-568-B and Class E requirements in ISO/IEC 11801-B.
  • Easy to install
  • Connector modules are grouped in sets of six
  • Panels contain both Universal T568A and T568B Wiring Configurations White IDC 110 punch down modules.
  • Color-coded front window labeling for easy port identification.
  • Centralized labeling is available on 48 port version
    (A centralized patch panel promotes greater visibility of labels when patch cords are routed into horizontal cable management above and below the patch panel.).
  • Termination standoff for optional grounding
  • Panels have a universal T568A and T568B wiring card for 110 style IDC Terminations.
  • Mounts on a standard 19" equipment rack
  • Universal U89 12 Port Patch Block is used for wall mount applications.
  • 16 gauge steel, painted black; PCB and plastic components are flammability rated UL94V-0
  • Leviton is an ISO 9001 Registered Quality Manufacturer
  • Click here to view Leviton Warranty Information

    •

    Property Value
    Material 16 gauge steel, painted black; PCB and plastic components are rated per UL 94V-0
    Capacity 12-, 24-, 48-, 96-port and U89 Universal
    12-Port Patch Block
    Dimensions 12, 24-port: 1.72" H x 19.0" W x 1.31" D
    48-port: 3.47" H x 19.0" W x 1.31" D
    96-port: 6.97" H x 19.0" W x 1.31" D
    89D Patch Block: 10.0" H x 2.30" W x 1.47" D
