Black Box® ClimateCab NEMA 12 Rated Enclosures

Climate-Controlled Protection for Sensitive Rackmount Equipment


BB-RM5007A
Qty:

What's special about these NEMA 12 cabinets?

  • Professional-quality server enclosures engineered to the NEMA 12 standard to provide sensitive electronics with excellent protection against dust, falling debris, dripping or splashing liquids, and other indoor contaminates.
  • AC ready for easy installation of a ClimateCab Air Conditioning Unit (sold separately), to provide superior thermal management for hardworking components without needing to cool the entire room.
  • Available in 24U and 42U rackmount sizes, with an adjustable 40 inch depth to accommodate a wide range of server, shelving, and power distribution installation requirements.
  • Click for More Features
  •
  • UL

Black Box® ClimateCab NEMA 12 Rated Enclosures provide a safe, climate-controlled solution for housing delicate server equipment in environments without a dedicated cooling infrastructure in place, such as a warehouses or machine shops. NEMA rated enclosures are designed to provide excellent protection against damaging outside elements, but when combined with a ClimateCab AC Unit, these enclosures also provide excellent thermal management that will help keep equipment running longer and at its maximum potential.

Part # Description Rack Height Dimensions Weight Price
BB-RM5007A ClimateCab NEMA 12 Server Cabinet with M6 Rails 24U 48"H x 24"W x 40"D
(121.9 x 60.1 x 101.6 cm)
338.0 lbs.
(153.3 kg)
Qty:
BB-RM5000A ClimateCab NEMA 12 Server Cabinet with M6 Rails 42U 82"H x 24"W x 40"D
(208.3 x 60.1 x 101.6 cm)
425.0 lbs.
(192.8 kg)
Qty:
Part # Description Rack Height Dimensions Weight Price
VMP-ER-S2U Solid Rack Shelf, 50lb Load Capacity
View more info
2U 3"H x 19"W x 14.75"D
(7.6 x 48.3 x 37.5 cm)
6.0 lbs.
(2.7 kg)
Qty:
VMP-ER-S2UV Vented Rack Shelf, 50lb Load Capacity
View more info
2U 3"H x 19"W x 14.75"D
(7.6 x 48.3 x 37.5 cm)
6.0 lbs.
(2.7 kg)
Qty:
BB-SP187A 19" Rackmount Surge Suppressor 400V
View more info
1U 1.8"H x 19"W x 2.8"D
(4.6 x 48.3 x 7.1 cm)
2.4 lbs
(1.1 kg)
Qty:
Part # Description Quantity Weight Price
HF-PM6CN M6 Cage Nut Package
View more info
20 0.2 lb
(0.1 kg)
Qty:
HF-ASM6 M6 Screw Package
View more info
20 0.2 lb
(0.1 kg)
Qty:
  • M6 rack rails, casters, levelers, doors, side panels, and top panel are all included to provide a complete, easy-to-order solution perfect for rush jobs and time-sensitive installations.
  • Openings are fully gasketed for enhanced protection against dust and moisture penetration.
  • Front door includes a safety glass window to offer a clear view of equipment for easy monitoring and inspection during maintenance.
  • 1500 lbs weight capacity for high-density applications.
  • Gland plate in base provides convenient cable management and routing.
  • Fully welded 12-gauge steel frame for increased durability and equipment load capacity.
  • 5 year Black Box® Double Diamond Warranty - view warranty
  • Proudly made in the USA Made in the USA
  •

    Part # BB-RM5007A BB-RM5000A
    Rack Units: 24U 42U
    Weight Capacity: 1500 lbs (680.4 kg) 1500 lbs (680.4 kg)
    Exterior Height: 51"H (129.5 cm) 84" (231.4 cm)
    Exterior Width: 24.0" (61 cm) 24.0" (61 cm)
    Exterior Depth: 41.2" (104.6 cm) 41.2" (104.6 cm)
    Equipment Depth: 36.2" (91.9 cm) 36.2" (91.9 cm)
    Weight: 338.0 lbs (153.3 kg) 425.0 lbs (192.8 kg)
    Cooling Method: Air conditioner Air conditioner

    Construction
    Frame: Welded 12-gauge steel with integral struts
    Front Door: 14-gauge steel with safety glass window
    Back Door: 14-gauge steel
    Sides: 14-gauge steel
    Finish: Phosphatized steel coated with black, low-gloss polyester powder paint

    Standards
    EIA RS-310-D
    UL 508A
    cUL C22.2 No. 94
    NEMA/EEMAC Type 12
