Brady Self-Sticking Vinyl Pipe Markers
Reliable Pipe Identification
BC-7110-3C
What's special about these pipe labels?
- Identifies the contents, directional flow, and hazardous status of pipes for overall safety.
- Made of B-946 Vinyl material that can be used indoors or outdoors for application versatility.
- Coated adhesive backing for ease of installation and handling.
- Meets ANSI A13.1-2007 requirements for piping system contents to keep your plant up to code and avoid fines.
- Click for More Features
Brady's Self-Sticking Vinyl Pipe Markers are perfect for labeling pipes of all types and sizes. These vivid color, clear type markers allow you to easily identify the contents and flow of a pipe as well as whether it is hazardous or not without even touching it. This safety labeling system is sure to keep your plant or facility up to code and help avoid hefty fines associated with violating safety regulations.
| For Pipes less than 3/4" Diameter - View Sample | |||||
|---|---|---|---|---|---|
| Part # | Marker Style | Marker / Card | Letter Height | Color | Price |
| BC-7110-3C | FIRE PROTECTION WATER | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Red Marker with White Text | Manufacturer Direct
|
| BC-7025-3C | BLANK | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Yellow Marker | Manufacturer Direct
|
| BC-7058-3C | COMPRESSED AIR | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Yellow Marker with Black Text | Quick Ship
|
| BC-7196-3C | NATURAL GAS | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7209-3C | OXYGEN | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7146-3C | HOT WATER | Three 2-1/4" x 2-3/4" & 8 Strips of Arrow Tape | 1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| For Pipes 3/4" to 2-3/8" Diameter - View Sample | |||||
|---|---|---|---|---|---|
| Part # | Marker Style | Marker / Card | Letter Height | Color | Price |
| BC-7110-4 | FIRE PROTECTION WATER | Four 1-1/4" x 7" | 3/4" | Red Marker with White Text | Manufacturer Direct
|
| BC-7025-4 | BLANK | Four 1-1/4" x 7" | 3/4" | Yellow Marker | Manufacturer Direct
|
| BC-7196-4 | NATURAL GAS | Four 1-1/4" x 7" | 3/4" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7209-4 | OXYGEN | Four 1-1/4" x 7" | 3/4" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7146-4 | HOT WATER | Four 1-1/4" x 7" | 3/4" | Yellow Marker with Black Text | Manufacturer Direct
|
| For Pipes 2-1/2" to 7-7/8" Diameter - View Sample | |||||
|---|---|---|---|---|---|
| Part # | Marker Style | Marker / Card | Letter Height | Color | Price |
| BC-7110-1 | FIRE PROTECTION WATER | One 2-1/4" x 14" | 2" | Red Marker with White Text | Manufacturer Direct
|
| BC-7025-1 | BLANK | One 2-1/4" x 14" | 2" | Yellow Marker | Manufacturer Direct
|
| BC-7058-1 | COMPRESSED AIR | One 2-1/4" x 14" | 2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7196-1 | NATURAL GAS | One 2-1/4" x 14" | 2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7209-1 | OXYGEN | One 2-1/4" x 14" | 2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7146-1 | HOT WATER | One 2-1/4" x 14" | 2" | Yellow Marker with Black Text | Manufacturer Direct
|
| For Pipes 8" Diameter or Larger - View Sample | |||||
|---|---|---|---|---|---|
| Part # | Marker Style | Marker / Card | Letter Height | Color | Price |
| BC-7110-1HV | FIRE PROTECTION WATER | One 4" x 24" | 3-1/2" | Red Marker with White Text | Manufacturer Direct
|
| BC-7025-1HV | BLANK | One 4" x 24" | 3-1/2" | Yellow Marker | Manufacturer Direct
|
| BC-7058-1HV | COMPRESSED AIR | One 4" x 24" | 3-1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7196-1HV | NATURAL GAS | One 4" x 24" | 3-1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7209-1HV | OXYGEN | One 4" x 24" | 3-1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
| BC-7146-1HV | HOT WATER | One 4" x 24" | 3-1/2" | Yellow Marker with Black Text | Manufacturer Direct
|
Ideal for use in:
| Adhesive Type | Permanent cold temperature pressure sensitive acrylic |
|---|---|
| Substrate Type | Vinyl film |
| Thickness (PSTC-133) | Total: 0.004" (0.125mm) |
| Adhesive Properties | Adhesion to Steel (PSTC-101) 15 Minute Dwell (avg) - 64 oz/in (70 N/100mm) Ultimate Dwell (72 hrs) (avg) - 79 oz/in (84 N/100mm) Adhesion to Polypropylene 15 Minute Dwell (avg) - 60 oz/in (70 N/100mm) Ultimate Dwell (72hrs) (avg) - 64 oz/in (70 N/100mm) Tack (ASTM D 2979) (avg) - 1147g Drop Shear (PSTC-107) (avg) - 14 hrs |
| Abrasion Resistance (Method 5306 of US Federal Test Method Std No 191A) | CS-10 wheels, 250g wts Legend withstands up to 400 cycles |
| Gloss | 47 Gardner Units |
| Minimum Application Temperature | 0° F (-18° C) |
| Service Temperature | -40° to 180° F (-40° to 82° C) |
| Average Outdoor Durability | 5 years (average expected outdoor life of product will depend on user definition of failure, climate, mounting techniques, and material color) |
| Shelf Life | 1 year when stored at 70° F (21° C) and 40% R.H. |
Chemical Resistance
| Reagent | 7 Day Immersion | Dip Test | Rub Test |
| 30% Sulfuric Acid | NE | NE | NE |
| 10% Sulfuric Acid | NE | NE | NE |
| 30% HCl | F | NE | NE |
| 10% HCl | NE | NE | NE |
| 50% NaOH | F | NE | NE |
| 10% NaOH | F | NE | NE |
| Methyl Ethyl Ketone | F | F | F |
| Acetone | F | F | F |
| Methanol | F | NE | F |
| IPA (Isopropanol) | F | NE | F |
| ASTM #3 Oil | NE | NE | NE |
| SAE 20 Oil | NE | NE | NE |
| Alconox® | F | NE | NE |
| Toluene | F | F | F |
| Mineral Spirits | F | NE | F |
| Glacial Acetic Acid | F | F | F |
| 5% Acetic Acid | NE | NE | NE |
| Diesel Fuel | F | NE | F |
| Heptane | F | NE | F |
| 10% Ammonia | NE | NE | NE |
| Turpentine | F | NE | F |
| Kerosene | NE | NE | F |
| Water | NE | NE | NE |
| Gasoline | F | NE | F |
NE = No Effect NT = Not Tested F = Failed (affected sample)
7 Day Immersion: Immersed in reagent for 7 days
Dip Test: Five 10 minute dips in reagent with 30 minute recovery
Rub Test: Rubbed sample for up to 100 rubs on Sutherland Ink rub tester
