Kendall Howard - Wall Mount Racks

Modular to Fit Many Rack Mounting Solutions


KH-1915-3-001-08
Qty:

What's special about this Kendall Howard wall mount rack?

  • 2-piece design is easily installed in just 5 minutes.
  • May be mounted to your desk, ceiling, or wall; use it anywhere.
  • Large side cutouts provide cable access.
  • Brilliant truss bar side panels result in a large weight capacity.
  • Click for More Features

When strength and simplicity is the name of the game, this wall rack mount by Kendall Howard is the perfect play. This rack provides 8U to 12U of space and has a 350 lbs weight capacity. To top it off, it sports a minimalistic, solid industrial look that can't be denied.

Part # IMG Description Height Width Depth Weight Price
KH-1915-3-001-08 Wall Mount Rack 8U 14.25" adjustable up to 24" 18" 12 lbs
Qty:
Manufacturer Direct
KH-1915-3-001-12 Wall Mount Rack 12U 21.25" adjustable up to 24" 18" 16 lbs
Qty:
Manufacturer Direct
Accessories
Part # IMG More Info Description Width Height Depth Load Capacity Weight Price
KH-1906-1-001-01 more info Rack Shelf 1U 19" 1.75" 12" up to 70 lbs 5.6 lbs
Qty:
Quick Ship
KH-1906-1-002-02 more info Rack Shelf 2U 19" 3.5" 14" up to 120 lbs 8 lbs
Qty:
Manufacturer Direct
KH-1906-1-003-03 more info Rack Shelf 3U 19" 5.25" 16" up to 150 lbs 9.6 lbs
Qty:
Manufacturer Direct
Part # IMG More Info Description Price
KH-0100-1-001-01A more info 10-32 Rack Screws (50 ct.)
Qty:
Manufacturer Direct
KH-0200-1-001-01A more info 10-32 Cage Nuts (50 ct.)
Qty:
Manufacturer Direct

The racks have a two-piece design which installs in less than 5 minutes and can support over 250 pounds. They are made from a system of steel truss cutouts in the side panels not unlike what you would see on a hanging bridge or home roof truss. Each bar or truss carries the weight of the one above it until the ultimate load is carried back to the wall itself. The strength is unprecedented and the wallmount will never pull away from the wall.

  • Available in 8 RMU and 12 RMU sizes
  • 16- gauge steel; 14- gauge rails
  • Adjusts to any size width: 19” EIA, 24” telecom or any width required
  • Desk mountable, wall mountable, ceiling mountable
  • Universal mounting holes for most common hardware
  • Side cutouts for easy cabling
  • Standard pre tapped 10-32 rail holes
  • Strength and durability of our Kendall Howard Modular Rack
  • Proudly made in the USA USA
  •

    Part # 1915-3-0012-08 1915-3-001-12
    Depth 18" 18"
    Width Adjustable for all equipment types up to 24"
    Height 14.25" 21.25"
    Weight 12 lbs 16 lbs
    Weight Capacity 350 lbs 350 lbs
    Material Rails: 0.90" thick steel
    Frame: 0.60" thick steel
    Related Articles





    How-To Corner





    Request A Quote

    Did you know that we can give you a quote for most of our products, including shipping?

    You can also call us toll free 1-833-3CABLEORG (1-833-322-2536)

    Questions & Answers

    Question:

    can 2 tl-SG108 SWITCHES be mounted side by side on one shelf

    Asked by Anonymous user on 09.47 AM Wednesday, 19 April, 2017

    Answer:
    • - Hello, The dimensions of the TL-SG108 are 3.94"D x 6.22"W x 0.98"H The dimensions of the KH-1915-3-001-08 are 18"D x Adjustable up to 24"W x 14.25"H The dimensions of the KH-1906-1-001-01 (the smallest shelf) is 12"D x 19"W x 1.75"H So, 2 TL-SG108 side-by-side measure 12.44"W so this rack and shelf will fit them with plenty of room. If you have any more questions about these products or any of our others, please don't hesitate to call toll free at 866-222-0030

      andrew b. on 02.57 PM Wednesday, 19 April, 2017
