Panduit Thermal Transfer Desktop Printer

Quickly Create High-Quality Identification Labels




What's special about these thermal transfer label printers from Panduit?

  • Panduit thermal transfer label printers creates high quality labels
  • Compact design enables use in the office or anywhere space is limited
  • 300 DPI thermal transfer creates crisp, clear labels and legible text
  • 4 inches/second print speed allows time and money saving
  • One button operation and auto-sensing gap detection reduces adjustment times
  • Click for More Features
RoHS CompliantCEUL ClassifiedFCCWaste Electrical and Electronic Equipment Directive

The TDP43ME Thermal Transfer Printer by Panduit® is a small form label printer designed to produce industrial level numbers of high quality labels. With easy to use software, this Panduit label printer presents itself as a must-have for any operation where making labels is necessary. A great selection of accessories for this Panduit label printer is also available, to ensure that all angles are covered.

Part #DescriptionWeightPrice
PAN-TDP43MEPanduit TDP43ME printer, Hybrid Ribbon, Easy Mark Software, AC Power Adapter w/US power cord, USB Cable, User Manual, Quick Start Card, and Driver Disk10.3 lbs
Manufacturer Direct
Part #DescriptionWeightPrice
PAN-TDP43M-ACYReplacement AC Power Adapter with power cord (US cord only)1.5 lbs
Manufacturer Direct
PAN-TDP43ME-RSExternal Label Roll Stand for rear feed labels, supplied on 3" cores1.9 lbs
Manufacturer Direct
PAN-TDP43ME-CASEHardside Carrying Case - Accommodates printer, AC power adapter, ribbons, printer cable, labels and tools9.8 lbs
Quick Ship

Panduit Military Grade Polyolefin Heat Shrink Labels
Thermal Transfer Component Labels
Thermal Transfer Marker Plates

Thermal Transfer Ribbons
Part #MaterialHeightWidthLengthPrice
PAN-RMH2BLWax/Resin Hybrid2.52"2.52"240 ft
Quick Ship
PAN-RMH4BLWax/Resin Hybrid4.33"4.33"240 ft
Manufacturer Direct
PAN-RMW2BLWax2.52"2.52"240 ft
Manufacturer Direct
PAN-RMW4BLWax4.33"4.33"240 ft
Manufacturer Direct
PAN-RMR2BLResin2.52"2.52"240 ft
Manufacturer Direct
PAN-RMER4BLResin4.33"4.33"240 ft
Manufacturer Direct
  • Setup and label loading are quick and easy - they take only minutes, for minimal down time
  • Manufactured of durable plastic to withstand the occasional bump or fall
  • Perfect for use on wire, cable, terminal blocks, conduit, control panels, and many other applications in the home, office or construction site


Recommended tape use:

  • Hybrid – Recommended for use with self-laminating, heat shrink, component and non-laminated labels
  • Wax – Recommended for use with self-laminating and non-laminated labels
  • Resin – Recommended for use with component labels, marker plates, and continuous tape


Ideal for printing on:


Resolution 300 dpi (12dot/mm)
Print Mode Thermal Transfer
CPU 32 Bit
Memory 4MB Flash, 8MB SDRAM
Print Speed  2 IPS~4 IPS
Print Length Min 12mm (1.47") Max 762mm (30")
Print Width 105.7mm (4.16")
Sensor Type Adjustable Reflective sensor; Fixed transmissive, center aligned
Sensor Detection Type: Label gap and black mark sensing.
Detection: Label length auto sensing and/or program command setting
Media Label Roll OD: Max. 4.92" (125mm)
Cord Diameter: 1" (25mm), 1.5" (38mm), 3" (76mm)
Width: 1" (25mm) ~ 4.64" (118mm)
Thickness: 0.0025" ~ 0.0098" (0.06~0.25mm)
Ribbon Length: 981 ft. (300M)
Max. Ribbon roll OD: 2.67" (68mm)
Type: Transfer ribbons (wax, hybrid, and resin) in widths of: 1.18" to 4.33" (30mm to 110mm)
Core Inner Diameter: 1" (25.4mm)
Printer Language EZPL Programming Language
Software DLL & Driver: Microsoft Windows 2000 and XP, Vista (32 & 64 bit); Microsoft Windows 7 (32 & 64 bit)
Easy-Mark Labeling Software
Image Handling Support BMP and PCX. Support ICO, WMF, JPG, EMF file through software. Support image resize, rotating, mapping and inverse through software.
Resident Barcodes Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128,UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping
Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, MaxiCode, HIBC, Plessey, Random Weight, Telepen,
FIM, China Postal Code, RPS 128, PDF417, Datamatrix code & QR code
Interfaces Serial port: RS-232 (Baud rate : 4800 ~ 115200 , Xon/Xoff , DSR/DTR )
USB port: V2.0
Parallel port: Bi-direction Ethernet TCP/IP Port (wireless – optional)
Control Panel Two Bi-color LED: Ready, Status Function Key: FEED
Power Auto Switching 100/240VAC, 50/60 Hz
Environment Operation: 41°F to 104°F (5°C to 40°C)
Storage: -4°F to 122°F (-20°C to 50°C)
Humidity Operation: 30-85%, non-condensing. Free air.
Storage: 10-90%, non-condensing. Free air.
Cert. Approval CE, FCC Class A, CCC, CB, cUL, RoHS, WEEE
Printer Dimension Length: 11.2" (285 mm)
Height: 6.8" (171 mm)
Width: 8.9" (226 mm)
Weight: 6 lbs. (2.72 Kg)



Model: TDP43M conforms to the following specification: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a) Class B digital device

Supplemental Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.



This device complies with Industry Canada ICS-003 class B Requirements. Cet equipment est conforme a l'ICS-003 classe B de la norm Industrielle Canadien.
