EverFocus® ECD 1080p Indoor Dome Camera

Top Quality Network Camera for Indoor Applications

Scroll To Pricing
We Guarantee to Have the Best Price

What's special about this IP dome camera?

  • 1080p Full HD with high flexibility and performance for astounding image
  • 1/2.9" Sony 2.24MP CMOS sensor, delivering amazing high sensitivity
  • Available in either 3.6mm or 6mm lens
  • D-WDR to improve the visibility under high contrast scene
  • Click for More Features
CEFCC

ECD dome camera exemplifies the best in high definition, reliable surveillance for indoor locations. This camera truly provides optimized images without compromising 1080p high resolution. The Digital Wide Dynamic Range function provides clear color images in the most challenging of bright or unbalanced lighting conditions.

Part #Horizontal ResolutionLensShutter TimePrice
EF-ECD900F1080p3.6mm / 6mm fixed lensAuto / Manual (x30 ~ 1/50,000) / FLK
Qty:
  • 3D-Noise Reduction ensures less blurry moving subjects, vivid and high SN ratio images even under low light environments
  • Supports 1080p, 720p & 960H analog signal output, which can be easily switched using OSD Joystick
  • Flexible angle viewing with 3-Axis rotation design for wall or ceiling mounting
  • eZ Controller function: Control camera OSD settings
Camera Features
Horizontal Resolution 1080p
Image Sensor 1/2.9" Sony 2.24MP CMOS
Video Format NTSC / PAL (Can be switched via OSD)
Image Pixels 1920 (H) x 1080 (V)
Scanning System Progressive Scan
Optical Zoom N/A
Lens 3.6mm / 6mm fixed lens
Sensitivity 0.003 Lux (Sens-up x30)
Shutter Time Auto / Manual (x30 ~ 1/50,000) / FLK
Video
Video Output BNC 1Vp-p, 75Ω
S/N Ratio > 48 dB (AGC OFF)
Gamma Correction 0.45
AGC 0 ~ 15 Levels
AWB Yes
BLC Off / BLC / HS BLC Selectable
HLC N/A
Function
White Balance ATW / AWC-SET / Indoor / Outdoor / Manual / AWB
DNR 2DNR / 3DNR, Off
WDR On / Off / Auto
Digital Zoom N/A
Privacy Mask Off / On for 4 selectable zones
Motion Detection Off / On for 4 selectable zones
OSD Menu English / Simplified Chinese / Traditional Chinese / German / French / Italian / Spanish / Polish / Russian / Portuguese / Netherlands / Turkish
Mirror Off / Mirror / V-Flip / Rotate
UTC Function Supported
Defog Off / Auto
General
IR LED (units) N/A
IR Distance N/A
Sync. Mode Internal
Water Resistant N/A
Vandal Proof N/A
Power Source 12VDC
Power Consumption 1.2W max.
Operating Temperature -10°C ~ 50°C / -14°F ~ 122°F
Humidity Less than 80%
Dimensions 108 x 90mm / 4.25" x 3.54"
Weight 1020g / 2.25lb
Certificates CE, FCC, RoHS
Power Supply 12VDC
Max. Power Consumption 12VDC 5.2W / PoE 5.8W
Operating Temperature

-10°C ~ 50°C / 40°F ~ 122°F

 Humidity

0% ~ 90% not condensing

 Dimensions

 120 x 95mm / 4.72" x 3.74"

 Weight

 200g / .44lb

 Safety Certifications

 CE, FCC, RoHS
