WireRun Manta Edge-Mount Charging Station

Power and USB Charging Ports for Tables and Desks

Qty:
We Guarantee to Have the Best Price

What's special about the Manta Desk Outlet?

  • Easy to assemble clamp mounting system for versatile installation without cutting into your work surface
  • Three power receptacles and two USB charging ports powered by a single 8ft power cord
  • Surge Protection 1000V, SPD Type 3 Tested
  • Screw clamp mount makes it easy to relocate this desk charging station on demand
  • Clamp mount can be removed and Manta can be used as a simple table surface power strip
  • Available in White and Black
  • Click for More Features
RoHS CompliantULUL Classified

This power and USB edge-mount desk outlet installs easily without cutting into your work surface. It has three power receptacles and two USB charging ports to add versatile connectivity to your desktop. Because of the edge-mount, it is easy to relocate this desk charging station as needed, when needed.


Part #DescriptionCord LengthOutletsColorPrice
WR-MANTA-PPPXX-96Manta Desk Outlet8ft3 Power, 2 USB ChargingBlack, White
Qty:
  • 8ft UL Rated Power Cord
  • Mount is shipped unassembled from power housing. Instructions for simple assembly are included
  • 2 USB Ports that have a combined output of 3.1A at 5V (No output for data transfer)
  • Mount has a built in holder for business cards or a mobile device.
  • 2.25 lbs. (0.90lb for the Mount + 1.35lbs for the housing and power cord)
  • Surge Protection, 510 Joules, SPD Type 3 Tested. Indoor use ONLY
  • Voltage Protection Rating: 1000V (L-N)
  • 3 x NEMA 5-15R / 15A 125V AC 50/60Hz
  • ROHS compliant
  • 5 year limited warranty
Manta Housing
Length Depth Height
7.125" (182 mm) 1.5" (39 mm) 2.2" (56 mm)



Manta Mount
Length Depth Height above table surface Total Height without clamp
3.4" (101 mm) 1.7" (43 mm) 3.2" (81 mm) 5.3" (135 mm)

MANUALS & USER GUIDES -



RELATED ARTICLES -



VIEW OUR GLOSSARY



we will beat a competitor's quote by 5%

Did you know that we can give you a quote for most of our products, including shipping?


You can also call us toll free 866-222-0030

Questions & Answers

Question:

What is the output on the USB ports?

Asked by Anonymous user on 02/23/2016 3:26 PM

Answer:
  • - The USB Charging Ports support a combined output of 2.1A, but that output does not need to be shared evenly between the two ports. For example, you can charge one device at 1.6A and another at .5A.

    Steve S. on 03/2/2016 10:29 AM
Question:

Mounting - What is the maximum width that this can be mounting to?

Asked by Anonymous user on 02/23/2016 6:55 PM

Answer:
  • - The clamping mechanism of the mount can accommodate table sizes ranging from 3/8" to 1-3/4" thick. Any table sizes outside of this range can still use the Manta as a stand alone power strip, however it must be used without the included mount.

    Steve S. on 03/2/2016 10:35 AM
Question:

Does this come in white?

Asked by Anonymous user on 01/25/2017 12:38 PM

Answer:
  • - Thank you for your question. This particular item does not come in white however, we do offer a variety of other options that do. Please give us a call at 866-222-0030 to discuss so that we can provide with a solution!

    Anonymous user on 01/27/2017 4:54 PM
Question:

I understand the table thickness can range from 3/8 to 1-3/4". How *deep* does the clamp grab the tabletop?

Asked by Anonymous user on 05/3/2017 12:10 PM

Answer:
  • - Hello, The dimensions of the Manta Mount (clamp) is 3.4"L, 1.7"D, and 3.2" Height above the table surface. So, the answer to your question is 1.7"is the depth of the clamp

    andrew b. on 05/3/2017 3:17 PM

Do you have any questions about this product?
Let our experts and customers resolve all your doubts

REVIEW SNAPSHOT®

by PowerReviews

5.0

(based on 1 review)

Ratings Distribution

  • 5 Stars



    (1)

  • 4 Stars



    (0)

  • 3 Stars



    (0)

  • 2 Stars



    (0)

  • 1 Stars



    (0)

Reviewed by 1 customer

Displaying review 1

Back to top


5.0

Perfect for my work station

By Melissa

from Florida

About Me Power User

Pros

  • Easy To Set Up
  • Easy To Use
  • Quality Construction

Cons

    Best Uses

      I use these constantly for work. I love that it is solid enough to not seem flimsy, but at the same time it is removable so your desk doesn't get damaged.
