FSR T3U-2 Tilt Up Table Top Box
More Plate Options For a Customized Desktop Connectivity Solution
LEFT INSERT
RIGHT INSERT
Available Jacks
What's special about this Power Data Center?
- Smooth looking low profile design keeps desk area functional when connections are not in use
- Multiple left and right plate options so that connections can be changed as the needs of the user change
- Allows you to easily access power and data ports
- Click for More Features
FSR’s T3U-2R Series was designed for placing multiple access boxes in the same table. The compact design and multiple plates easily accommodate a wide variety of data, power, and AV connections in a low profile box that will match just about any décor. The T3U can be easily installed in any table surface from 3/4" to 2-3/4" thick.
Please Note: These products ship in 3-5 business days
| Part # | Description | Length | Width | Depth | Weight | Price |
|---|---|---|---|---|---|---|
| FSR-T3U-2R | Table Box- Double Insert, AC Duplex | 8.5" | 5.75" | 5.44" | 4 lbs | Manufacturer Direct |
* Custom Orders
Because they're specifically tailored to your individual needs and are therefore not resellable, we're unable to accept returns on custom-ordered items of any sort. The only circumstances under which we will allow the return of a custom order is if the item has a manufacturing defect.
| Choose at least 1 of the following left side inserts for your box | ||||||
|---|---|---|---|---|---|---|
| Part # | Openings | Image | Length | Width | Weight | Price |
| FSR-T3U-2-L2SCP | (1) Cable Pass Thru (2) Snap-in connectors |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-L2SHD | (2) Snap-in connectors, (1) HD-15 |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-L4S | (4) Snap-in connectors |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-LCP | (2) Cable Pass Thru |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-LPT | (1) Blank Plate Insert to be custom punched |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-LCRST2S | Crestron Block 10, (2) Snap-in connectors |  | 2.65" | 2.2" | 1.2 lbs. | Manufacturer Direct |
| Choose at least 1 of the following right side inserts for your box | ||||||
|---|---|---|---|---|---|---|
| Part # | Openings | Image | Length | Width | Weight | Price |
| FSR-T3U-2-RCI5 | (1) CI-5 |  | 2.65" | 2.5" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-RCP | (2) Cable Pass Thru |  | 2.65" | 2.5" | 1.2 lbs. | Manufacturer Direct |
| FSR-T3U-2-RPT | Blank Plate to be custom punched |  | 2.65" | 2.5" | 1.2 lbs. | Manufacturer Direct |
| Available Jacks | |||
|---|---|---|---|
| Part # | Description | Color | Price |
| LE-6S180-SH6 | CAT6 Shielded QuickPort Connector | White | Manufacturer Direct |
| LE-41106 | USOC QuickPort Snap in Connector, 6 conductor | White | Manufacturer Direct |
| LE-41084-BGF | BNC Adapter Nickel-plated, 75ohm | Gray | Manufacturer Direct |
| LE-40735 | QuickPort RCA 110-Type | White | Quick Ship |
| LE-40830 | QuickPort RCA, Gold-Plated Connector with Black Stripe | White | Quick Ship |
| LE-41084-BGB | Blank Insert | Gray | Quick Ship |
| FSR-SS-HDMI-BLK | HDMI Coupler | Black | Manufacturer Direct |
| FSR-SS-RJ11 | RJ-11 Coupler | Black | Manufacturer Direct |
| FSR-SS-RJCAT6-BLK | CAT6 Coupler | Black | Manufacturer Direct |
| FSR-SS-USBA-BLK | USB-A Coupler (Power/Data) | Black | Manufacturer Direct |
| FSR-SS-USB-CHRG | USB Charging Port w/ Power Supply | Black | Manufacturer Direct |
Select from the below list of available options to see it on the left.
NOTE: Due to differences in monitor settings, the examples show may vary slightly from the actual product.
NOTE: Not all options may be represented.
- Accommodates standard snap-in connectors
- Specially designed top works off of the weight of the top, uses no springs or hydraulics to open and close
- UL NWGQ.E213473
- Includes 6' NEMA 5-15 SJ cord set to support the 2 duplex receptacles
- Ideal for use in offices, meeting rooms, home office, conference tables, classrooms, computer labs
- Available in 4 different finishes to match just about any décor
- Black
- Brushed Brass
- Brushed Bronze
- Brushed Nickel
* Custom Orders
Because they're specifically tailored to your individual needs and are therefore not resellable, we're unable to accept returns on custom-ordered items of any sort. The only circumstances under which we will allow the return of a custom order is if the item has a manufacturing defect.
| Part # | FSR-T3U-2R |
| Color Options: | Black, Brass, Bronze, Nickel |
| Hole Dimensions: | 8"L x 5.38"W |
| Power Outlets: | 2 AC |
| Power Cord Set: | 6' NEMA 5-15 SJ Included |
| Inserts Needed: | (1) Left and (1) Right |
| Depth under table: | 3.5" |
| Ratings: | UL NWGQ.E213473 |
| Dimensions: | 8.5"L x 5.75"W x 5.44"D |
| Weight: | 4 lbs. |
Specifications for Left Side Plate Inserts
|
|
|
|
|
|
|
| Part # | FSR-T3U-2-L2SCP | FSR-T3U-2-L2SHD | FSR-T3U-2-L4S | FSR-T3U-2-LCP | FSR-T3U-2-LPT | FSR-T3U-LCRST2S |
| Connections: | (1) Cable Pass Thru (2) Snap-in connectors |
(2) Snap-in connectors, (1) HD-15 |
(4) Snap-in connectors | (2) Cable Pass Thru | (1) Blank Plate Insert to be custom punched | Crestron Block 10, (2) Snap-in connectors |
| Pieces: | 2 | 1 | 1 | 2 | 1 | 1 |
| Dimensions: | 2.65" L x 2.2"W | 2.65" L x 2.2"W | 2.65" L x 2.2"W | 2.65" L x 2.2"W | 2.65" L x 2.2"W | 2.65" L x 2.2"W |
| Weight: | 1.2 lbs. | 1.2 lbs. | 1.2 lbs. | 1.2 lbs. | 1.2 lbs. | 1.2 lbs. |
Specifications for Right Side Plate Inserts
|
|
|
|
| Part # | FSR-T3U-2-RCI5 | FSR-T3U-2-RCP | FSR-T3U-2-RPT |
| Connections: | (1) CI-5 | (2) Cable Pass Thru | Blank Plate to be custom punched |
| Pieces: | 1 | 2 | 1 |
| Dimensions: | 2.65"L x 2.5"W | 2.65"L x 2.5"W | 2.65"L x 2.5"W |
| Weight: | 1.2 lbs. | 1.2 lbs. | 1.2 lbs. |
