Sidewalk Sleever® Pipe Installation Tool
The Best New Tool and Method for Pipe Installation
Close Window
Sidewalk Sleever®
This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player |
Sidewalk Sleever® was invented by a landscape/irrigation company that understands the demands of an everyday job site. What used to consume about a half-day’s worth of work now takes about 1 minute with this fabulous tool. More |
Pipe installation has never been so quick and easy, this method has revolutionized many industries such as: irrigation installers, landscapers, lighting installers, plumbers, electricians, cable TV installers, municipalities, and even homeowners.
- Various sizes available to fit your application
- One step installation saves time for an overall labor savings
- Pull-through feature allows you to pull wires through pipe while installing (only available on 60” models)
- Patented design (US Patent #’s 1433.001, 1433.006, & 1433.007)
- Steps on how to use Sidewalk Sleever®
| PART # | TOOL LENGTH | SLEEVE DIAMETER | DESCRIPTION | WEIGHT |
| SS-5740 | 60" | 1" | Installs 1" PVC (class and sch.40) Electrical Conduit | 13 lbs |
| SS-7240 | 72" | 1" | Installs 1" PVC (class and sch.40) Electrical Conduit | 16 lbs |
| SS-9640 | 96" | 1" | Installs 1" PVC (class and sch.40) Electrical Conduit | 21 lbs |
| SS-6040 | 60" | 2" | Installs 2" PVC (class and sch.40) Electrical Conduit | 18 lbs |
| PART # | DIMENSIONS | WEIGHT / UNIT | UNITS / PACK | PRICE / PACK |
| UPI-SS-5740 | 1" dia. x 57" length | 13 lbs | 1 | |
| UPI-SS-7240-4 | 1" dia. x 72" length | 16 lbs | 4 | |
| UPI-SS-9640-4 | 1" dia. x 96" length | 21 lbs | 4 | |
| UPI-SS2-6040 | 2" dia. x 57" length | 18 lbs | 1 |
 |
 |
 |
| Step 1 Measure and cut your pipe accordingly with one end on the "pipe stop" head of the Sidewalk Sleever and the other end as far as the tapered to avoid dirt accumulation. |
Step 2 Make sure Sidewalk Sleever is clean to avoid dirt which would make the extracting step difficult. Cut pipe and slide it onto the Sleever. |
Step 3 Place the pipe and Sleever right underneath concrete or other surface and tap in a few inches. This allows the Sidewalk Sleever to hold itself making the installation easier. |
 |
 |
 |
| Step 4 Use a 16lbs sledge hammer to push in the Sidewalk Sleever. |
Step 5 Repeat until the tapered end shows up on the other side. |
Step 6 When the tapered end appears on the other side, simply grab the head and pull the Sidewalk Sleever out, leaving the pipe installed. |
 |
 |
 |
| Step 7 Shows pipe installed in less than 2 minutes. |
Step 8 Repeat steps for more quick installations. |
Step 9 Pipe shown with wire-through feature. |
