EverFocus® HD Hybrid 16 Channel DVR

Ultra-high Quality in Real Time

Low Price Guarantee

EF-EDR-HD-2H14-2

What's special about this analog and HD DVR?

  • 2 Channels record in full 1080p, 14 record analog video; this allows you to put resources where they are most needed
  • HDMI output allows all channels to be viewed in full1080p
  • Choose 2, 4, 6, or 8 TB of storage + an optional 8 TB through the eSATA port for massive storage possibilities
  • Internal DVD burner lets you make portable records on-the-fly
  • PTZ functions can be controlled on-screen, over network, and from any web browser
  • 16x digital zoom lets you get up close & personal without destroying the quality
  • Click for More Features
ULCE logo

Analog video is still currently being used in nearly every CCTV application in the world, and with great results. But in certain areas, nothing less than the clearest video will do. This hybrid DVR gives you 2 1080p/720p HD channels and 14 analog channels, so you put the best quality where it's needed the most while keeping costs down and storage utilization efficient.

Images

*All channels require HD cameras, even the analog channels.
Keep in mind that all channels are viewable in HD, but only 2 are recordable in HD

EverFocus HD Hybrid DVR (2 HD Channels, 14 Analog Channels)
Qty:
  • Includes brackets for mounting to a 19" rack if desired
  • MobileFocus app for remote access and operation are available for Android, Apple (iPhone, iPad), and Blackberry



*All channels require HD cameras, even the analog channels. Keep in mind that all channels are viewable in HD, but only 2 are recordable in HD



Property Value
Type Hybrid 2 HD Ch / 14 Analog
Total Camera Inputs 16
HD CCTV Camera Inputs (BNC SMPTE292m) 2
Analog Camera Inputs 14 BNC
Looping Analog Cam Outputs 14 BNC
1080p 30 FPS NTSC | 25 FPS PAL
or 720p 60 FPS NTSC | 50 FPS PAL
D1 420 FPS NTSC | 400 FPS PAL
Pentaplex Operation Simulatneous Live, Recording, Playback, Archive and Remote Viewing
Video Ouput Main Monitor 1080p HDMI Socket | VGA: 1920 x 1080 @ 60Hz
External HDD Support 1 eSATA
Audio 16 Inputs / 2 Outputs
Recording Mode Manual, Schedule, Event
Playback Search Date/Time, Event, Smart Snapshot, Text
Alarm In/Out 16 Alarm Inputs | 4 Alarm Outputs | Form "C" rated at 30VDC, 1A
OS/Interface Embedded Linux with Graphical User Interface
Network Gigabit Ethernet + FREE DDNS from EverFocus
USB 2 USB 2.0 Ports
DVD Burner Built-in DVD Burner
User Access 3 Levels of User Access
RS-485 1 RS485 (2 RJ45 Connector)
PTZ Protocols EverFocus, Pelco-P, Pelco-D, Samsung, Transparent
Power Source 100VAC ~ 240VAC
Power Consumption 100 W. Max with 4 x HDDs
Dimensions 16.6" x 16.9" x 3.2"
Operating Temp 32° to 104° F
Certificates EC, FCC, UL
