Speaker Seeker™ Wiremapping Tester

Quickly Identify Both Ends of Up to 20 Unterminated Twisted Pair or Coax Cables

DISCONTINUED

JDSU-TP410

Close Window

Speaker Seeker™ Wiremapping Tester

    Additional Images
  • JDSU Speaker Seeker™ Wiremapping Tester, TP-410 - icon
  • JDSU Speaker Seeker™ Wiremapping Tester description - icon

This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player
Copyright ©2014 CableOrganizer.com

Low Price GuaranteeWhat's special about this speaker seeker?

  • Allows a single user to identify both ends of up to 20 cables at once, saving time and money on installations
  • Bright LED display shows the number of the ID-only remote at the end of the cables, for quick and easy terminations
  • Automatically powers "on" when in use, and "off" after use to prolong battery life
  • Perfect tool for maintenance of coax or twisted pair cables; also identifies both ends of unterminated speaker, security and alarm cables, so you can use just one meter for multiple jobs
  • Click for More Features
DISCONTINUED

The Speaker Seeker™ Cable Tester by JDSU can identify up to 20 unterminated twisted pair or coax cables, comes with alligator clip or F-connector contacts, is capable of voltage detection and warning, and automatically turns on and off to save power. With such a lineup of features, this versatile wiremapper is not only perfect for the installation or maintenance of alarm and security cables, but for speaker and A/V cable run as well.

  • Two different connections (alligator and F-connector styles) available on one unit
  • Alligator clips attach to bare wire
  • F-connector are compatible with preexisting cable connections
  • Rugged test contact surfaces with through holes for test probe tests
  • Voltage detection and warning signal to protects you and the unit from accidents
  • Coax-to-alligator clip adapter included, which allows for a wider range of applications, including loose wiring



JDSU-TP410 DISCONTINUED
Battery Life Standby: 2.5 years
Testing: 20 hours
Cable Resistance 100 maximum DC resistance, sum of both conductors
Input Protection Up to 100V DC or AC, RMS continuous
200V peak for 5 second maximum
Operating Temp. 32° to 122°F (0° to 50°C)
Storage Temp. –40° to 70°C (–40° to 158°F)
Humidity 10 to 90%, non-condensing
Length 4.75" (12cm)
Width 2.75" (7cm)
Height 1.2" (3cm)
Weight w/ Battery 5.1oz (145 g)
Warranty 1 year
PART # DESCRIPTION DIMENSIONS COLOR WEIGHT PRICE
JDSU-TP410 Speaker Seeker Wire Mapper(with 20 individually-numbered alligator clip wiremappers) 4.75"L x 2.75"W x 1.2"H
(12cm x 7cm x 3cm)
Yellow 0.5 lb DISCONTINUED
