Greenlee L Series Battery-Powered 4-Ton Crimping Tool
This Streamlined Hydraulic Crimper is Quick and Powerful
Close Window
Greenlee Gator Plus Battery-Powered 4-Ton Crimping Tool
This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player |
With Greenlee EK410 Series, you get sleek, compact, battery-operated tools with the capacity to crimp 300 kcmil (mcm) copper color-coded connectors, as well as 5/8" and 840 service entrance connectors. These features, combined with an integrated LED, make this lightweight crimper ideal for one-handed operation. |
Crimping head can rotate 360° to reach awkward hanging cables
- Ram automatically retracts to signal that the crimp has been completed
- 4-ton crimping force to protect the toughest and thickest cables
- A built-in LED light to illuminate the work area for safety
- Over-molded tacky grip area makes the tool easier, and more comfortable, to hold and handle
- Ram can be retracted in mid-cycle to adjust the connector
- Battery can deliver up to 200 crimps per charge
- UL rated 468B, cUL Classified with Anderson, Blackburn, Burndy, ILSCO, Panduit, Penn-Union, and Thomas & Betts copper and aluminum color-coded connectors
| Part # | GL-EK410L11 | GL-EK41012 | GL-EK41022 |
|---|---|---|---|
| Price | |||
| Crimping Die Style | 4 Ton | 4 Ton | 4 Ton |
| Crimping Force | 7,900 lbs (35kN) | 7,900 lbs (35kN) | 7,900 lbs (35kN) |
| Length | 13-1/4"(337mm) | 13-1/4"(337mm) | 13-1/4"(337mm) |
| Width | 2-7/8" (73mm) | 2-7/8" (73mm) | 2-7/8" (73mm) |
| Depth | 4-1/2" (114mm) | 4-1/2" (114mm) | 4-1/2" (114mm) |
| Weight | 11 lbs | 11 lbs | 11 lbs |
| Battery | 18V 3.0 Ah Li-ion | 18V 3.0 Ah Li-ion | 18V 3.0 Ah Li-ion |
| Ext. Cycles/charge | 200 | 200 | 200 |
| Battery Charger | 120V | 12V | 230V |
| PART # | DESCRIPTION | WEIGHT | PRICE |
| GL-EK410L11 | 4-Ton Battery-Powered Crimping Tool, 120V Charger | 11 lbs | |
| GL-EK41012 | 4-Ton Battery-Powered Crimping Tool, 12V Charger | 11 lbs | |
| GL-EK41022 | 4-Ton Battery-Powered Crimping Tool, 230V Charger | 11 lbs | |
| Accessories | |||
| GL-52177 | Replacement Battery for EK410L11 | 2 lbs | |
| GL-KC4CU | Copper Die Kit | 1.75 lbs | |
| GL-KA4AL | Aluminum Die Kit | 0.123 lb | |
