HelleramnnTyton® Metallic Compression Fittings
HT-FSU16-FSU16
What's special about these fittings and accessories?
- Nickel plated brass compression fitting used with FSU, LFHU and FPU flexible metallic conduit.
- Fitting includes elastomeric sealing washer for IP65 ingress protection.
- Suitable for knockouts or NPT / Metric threaded entries as fitting rotates until tightened.
-
Multipart straight compression fitting with fixed external thread pattern suitable for threaded or knockout entries. Constructed with nickel plated brass components that resist corrosion, ensures high mechanical strength and electrical continuity. Fitting comprised of body, nut, grounding ferrule and nylon compression seal. For use with FSU, FPU, and LFHU flexible metal conduits. Two-part nickel plated brass straight fitting with fixed external metric thread. Fitting comprised of shell and body suitable for knockout entries. For use with FU-x flexible metal conduit.
| Part # | Description | Dimensions | Material, Quantity | Price |
|---|---|---|---|---|
| HT-FSU16-FSU16 | Metallic Compression Fitting, Flexible, Coupler | 0.38" (16mm) to 0.38" (16mm) Dia | NPB Metal, 2/pkg | Manufacturer Direct
|
| HT-FSU16-M20-C | Metallic Compression Fitting, Straight, M20 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FSU20-M20-C | Metallic Compression Fitting, Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FSU40-M40-C | Metallic Compression Fitting, Straight, M40 Metric Thread | 1.25" (40mm) Dia | NPB Metal, 1/pkg | Manufacturer Direct
|
| HT-FSU20-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FU16-M16-M | Metallic Compression Fitting, Fixed Straight, M16 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FU16-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FU20-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FU25-M25-M | Metallic Compression Fitting, Fixed Straight, M25 Metric Thread | 3/4" (25mm) Dia | NPB Metal, 10/pkg | Manufacturer Direct
|
| HT-FU32-M32-M | Metallic Compression Fitting, Fixed Straight, M32 Metric Thread | 1" (32mm) Dia | NPB Metal, 2/pkg | Manufacturer Direct
|
| HT-FU40-M40-M | Metallic Compression Fitting, Fixed Straight, M40 Metric Thread | 1.25" (40mm) Dia | NPB Metal, 2/pkg | Manufacturer Direct
|
| Part # | Description | Diameter | Material, Quantity | Length X Height (Imperial) | UV Resistant | Operating Temp. | Reach Compliant (Article 33) |
|---|---|---|---|---|---|---|---|
| HT-FSU16-FSU16 | Metallic Compression Fitting, Flexible, Coupler | 0.38" (16mm) to 0.38" (16mm) Dia | NPB Metal, 2/pkg | 1.56 X 1.14 | No | -58°F to +275°F (-50°C to +135°C) | Yes |
| HT-FSU16-M20-C | Metallic Compression Fitting, Straight, M20 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | 1.3 X 0.83 | No | -58°F to +275°F (-50°C to +135°C) | Yes |
| HT-FSU20-M20-C | Metallic Compression Fitting, Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | 1.32 X 0.85 | No | -58°F to +275°F (-50°C to +135°C) | Yes |
| HT-FSU40-M40-C | Metallic Compression Fitting, Straight, M40 Metric Thread | 1.25" (40mm) Dia | NPB Metal, 1/pkg | 1.87 X 1.25 | No | -58°F to +275°F (-50°C to +135°C) | Yes |
| HT-FSU20-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | 1.03 X 0.94 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU16-M16-M | Metallic Compression Fitting, Fixed Straight, M16 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | 0.98 X 0.79 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU16-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 3/8" (16mm) Dia | NPB Metal, 10/pkg | 0.98 X 0.87 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU20-M20-M | Metallic Compression Fitting, Fixed Straight, M20 Metric Thread | 1/2" (20mm) Dia | NPB Metal, 10/pkg | 1.03 X 0.94 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU25-M25-M | Metallic Compression Fitting, Fixed Straight, M25 Metric Thread | 3/4" (25mm) Dia | NPB Metal, 10/pkg | 1.16 X 1.14 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU32-M32-M | Metallic Compression Fitting, Fixed Straight, M32 Metric Thread | 1" (32mm) Dia | NPB Metal, 2/pkg | 1.46 X 1.42 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
| HT-FU40-M40-M | Metallic Compression Fitting, Fixed Straight, M40 Metric Thread | 1.25" (40mm) Dia | NPB Metal, 2/pkg | 1.54 X 1.89 | No | -58°F to +572°F (-50°C to +300°C) | Yes |
