Ground Fault Circuit Interrupter (GFCI) Receptacles

Protects Against Electrocution and Fire When Ground Faults Occur

Click for larger view - 15A GFCI Receptacle

What's special about these receptacles?

Protects against shocks, electrocution, and fire that can occur from ground fault currents
National Electrical Code (NEC) requirement for outlets in the bathroom, kitchen, outdoor, basement, garage, or any other place that electricity and water will be in close proximity to one another
Monochromatic receptacle, wall plate and button assembly gives outlets a neat, finished, and unobtrusive appearance

Our Ground Fault Circuit Interrupter (GFCI) will protect you against the risk of electrical shocks or fires that are caused by ground fault currents, which can escape from electrical equipment whose insulation has been damaged. More

Price
Features
Specifications
Manuals
Reviews
Related Items

In order to prevent reverse wiring and current leakage, GFCIs can be used to replace standard duplex outlets in homes, offices, schools, hotels, industrial settings and retail spaces.
The National Electrical Code (NEC) requires the use of GFCI protection on most outdoor, kitchen, garage and unfinished-basement outlets, as well as bathroom receptacle circuits.

Our GFCIs feature an elegant design, and are UL-certified. We offer them in white and ivory to complement any decor.

2006 UL Listed (UL 943)
Choose from 15A or 20A, in White or Ivory colors
125VAC 60Hz
Monochromatic buttons with wall plate

Click to view larger

Dimensions (Inches)
A	3.81 ± 0.004
B	3.68 ± 0.004
C	3.28 ± 0.004
D	2.73
E	2.70
F	1.69
G	1.30
H	0.94 ± 0.004
I	1.55
J	1.30

Electrical Specifications
ANSI/NEMA	5-15R, 5-20R, WD-6
Dielectric Voltage Withstands	1500V per UL498
Current Interrupting	10KA/6KV
Temperature Rise Max	30C after 50 cycles OL at 150 pct rated current
Mechanical Specifications
Terminal ID Brass-Hot, Green Ground, White Neutral Terminal Accommodation	14-1 2 AWG
Product ID Ratings are permanently marked on device

Material Specifications
Face Material	Polycarbonate
Body Material	Polycarbonate
Line Contacts	Brass Double-Wipe 0.031 Thick
Terminal Screws	Brass 8-32
Grounding Screws	Brass 8-32
Strap	Zinc-Plated Steel 0.050 thick
Clamps	Zinc-Plated Steel
Ground Clip	Brass
Internal Switch Contacts	Silver and Tin Alloy
Available Colors	White or Ivory

Environmental Specifications
Flammability Rated	V-2 per UL94
Operating Temperature	-35° C to 65° C

Performance Data
Trip Level	5mA ± 1mA

AC Horsepower Ratings
At Rated Voltage	1-1/2 HP

The end-of-life intellectual monitoring function
When the GFCI reaches its end of life the red indicator will turn on If the GFCI red indicator turns on it reaches its end of life If no power output the GFCI reached its end of life

Standards and Certifications
NEMA WD-6 ANSI WD-6 UL 498 File E243553 UL943-2006 requirements Class A File E229322 CSA C22.2 No. 42 File LR-57811 NOM 057

2006 UL Listed 15A / 20A Duplex GFCI Receptacle with LED Indicator Light

PART #	DESCRIPTION	WEIGHT	COLOR	PRICE
2004 UL Listed
WTS-TG15-L	GFCI 15A Duplex Receptacle, monochromatic buttons with wall plate, LED indicator light	0.30 lb	White	$6.99 Qty:

2006 UL Listed
WTS-TGS15A	GFCI 15A duplex receptacle, monochromatic buttons with wall plate, LED indicator light	0.30 lb	Ivory	$6.99 Qty:
WTS-TGS20A	GFCI 20A duplex receptacle, monochromatic buttons with wall plate, LED indicator light	0.30 lb	Ivory	$7.19 Qty:

RELATED ARTICLES -

VIEW OUR GLOSSARY

REVIEW SNAPSHOT®

by PowerReviews

GFCI 15A duplex receptacle, UL 2006

3.0

(based on 1 review)

REVIEWS

Reviewed by 1 customer

Displaying review 1

4/3/2008

(2 of 2 customers found this review helpful)

3.0

Not so Fast

By Bob

from Tucumcari, NM

About Me Tech Savvy

Pros

Easy To Install

Cons

Some do not work

Best Uses

Home

Comments about GFCI 15A duplex receptacle, UL 2006:

So far....2 of the units did not work. I still have six to test though.
