Middle Atlantic EWR Series Wall Mount Rack

• Opens from the left or right for easy access.
• Contains plenty of knockouts for cable entry/exit.
• Tool-less, one-person installation reduces labor times.
• 17" and 22" depths work for a variety of applications.
• Weight capacity of 150 lbs. will definitely support anything that fits inside.

• Attractive and durable black textured powder coat.
• Solid locking front doors available.
• UL listed in the US and Canada
• EIA/TIA Compliant
• Proudly made in the USA

Thermal Management Features

The EWR cabinets are vented to facilitate optimum passive thermal management

Cable Management Features:

• 1/2", 3/4”, 1” and 1-1/2” electrical knockouts and UHF/VHF antenna knockouts are located on top and bottom of backpan
• Extensive lacing points throughout the interior of the cabinet facilitate cable management
• The large opening in the backpan provides a 10-1/2” x 10-1/2” pull box sized opening for convenient cable passage

The EWR has a standard 3 position front 1/8”, 5/8” and 1-1/4” adjustable 11-gauge, 10-32 threaded rack rail with marked space increments to quickly mount equipment. Rack rails are finished in a durable “e coat” to guarantee no clogged threads. The backpan includes integral mounting clips to mount optional power strips. The padlock able center section is reversible and keyed separately from the optional front door. Convert the EWR to full front-to-rear adjustable rackrail with Middle Atlantic Rack Rail Bracket Extenders.
