High Density Slim Power Strips


What's special about these power strips?

  • UL and CSA listed
  • Slim low profile design requires less space
  • 8 Outlets (with options up to 24 outlets)
  • Outlets spaced to accommodate plug in power supplies
  • Click for More Features
  • RoHS CompliantULCSA ApprovedGreenguard Certification

Our high density slim power strips are a perfect accessory to your Middle Atlantic home theater ASR-HD rotating shelf system. They are also perfect for many applications where you want to maximize every outlet using a minimum amount of space for low voltage applications. They contain 8 outlets that have been spaced to accommodate plug in power supplies, resulting in no wasted outlets!

Part # Circuit Termination Protection # of
MA-PD-815SC-NS 15 Amp (1) 10' Cord w/NEMA 5-15P plug Circuit Breaker 8 18"
Manufacturer Direct
MA-PD-815SC 15 Amp (1) 10' Cord w/NEMA 5-15P plug MOV surge + EMI filter + breaker 8 18"
Manufacturer Direct
Mounting Brackets
Part # Description Weight Price
MA-PB-DWR Brackets required to vertically mount power strips in DWR & SR Series wall racks 1.1 lbs
Manufacturer Direct
MA-PB-XS Brackets required to horizontally mount power strips PD-815SC/815SC-NC in standard 19" racks 1.1 lbs
Manufacturer Direct
  • Lightweight aluminum chassis
  • One 15 Amp circuit
  • Mounting Hardware included
  • Includes 10” power cord terminated with NEMA 5-15P plug
  • Black

    These unique high density slim power strips measure 1-1/4” deep by 1-5/8” wide. Complete with a 10’ power cord and NEMA5-15P plug, they are UL and CSA listed in the USA and Canada.

    Included with all power strips is Middle Atlantic’s “quick clip” mounting system, which provides fast and secure mounting.
    These unique Quick clips and mounting lances to attach to rack rail brackets on all Middle Atlantic racks. Quick clips may also be used to attach to wood racks as well as to walls and other surfaces by using appropriate fasteners. Once the quick clips are fastened to the inside of the rack, the power strip is hung in place via a series of mounting lances found along its sides. These lances double as cable tie points, allowing all AC cables to be neatly managed!


    diagram showing attachment of power strips

    Part # MA-PD-815SC MA-PD-815SC-NS
    Fits Racks Coded C C
    # of Outlets 8 8
    Circuit(s) (1) 15 amp (1) 15 amp
    Protection MOV surge + EMI filter + breaker Circuit breakers
    # of Plug-In Power Supplies Accommodated 3 3
    Length Power Cord 10 ft 10 ft
    Height 18.0" [457mm] 18.0" [457mm]
    Width 1.625" [41mm] 1.625" [41mm]
    Strip Color Black Black
    Outlet Color Gray Gray
    Chasis Lightweight anodized aluminum Lightweight anodized aluminum
    Power Strip Depth 1.25" [32mm] 1.25" [32mm]
    Overall Depth 1.44" [37mm] 1.44" [37mm]
    Weight 2.0 lbs 2.0 lbs
    UL UL 1363, file #128811 UL 1363, file #128811
