Great Lakes Wall Mount Enclosures - WS Series
Great Lakes Wall Mount Enclosures - WS Series
The Wall Mount/Swing Out WS Series Enclosures provide 19" 310-E compliant mounting in a heavy duty distribution unit. This durable enclosure features a center swing out section for outstanding front and rear access to cables and equipment. A simple finger pull-latch mechanism located inside the enclosure swings the 18.375" deep center swing section open from the rear.
Part Number: QGL-GL24WS-SV-EA
Couldn't load pickup availability
What's Special
What's Special
- Made of 14 Gauge cold rolled steel fully welded; front door is made from 12 Gauge.
- UL listed per STD 508, Type 1
- UL 2416
Features
Features
- ISO 9001:2000 registered
- Choose your front door style (solid or plexiglas)
- Front door locks
- Interchangeable side panels
- Two pairs of 12-24 tapped 19" EIA rails (12 Gauge), adjustable front to rear are provided with each enclosure.
- Swing out center section
- Front and rear cable access
- Provisions for 2 low profile 75 cfm fans at top or bottom (does NOT include fans).
- Knockouts designed for 1", 2", and 3" conduit at top, bottom and rear sections.
- Reversible mounting to conserve space
- Easy wiring, installation and maintenance
Great Lakes Features:
- 8 week shipping time on custom changes
- Custom colors available upon request (Additional charge may apply. Please allow up to an additional 4 week ship time)
- Custom configurations assembles in 24-48 hours
- Accessories installed where you specify
No additional freight charges for installed options
- Shelves placed where you specify
- Mounting rails located where you specify
- Cable Management installed where you specify
- Power outlet strips installed where you specify
No additional cost for drop ship
All enclosures have a Serial Number
Remote installation of equipment before wiring is possible with a set of optional casters. They increase the weight capacity and stability of the enclosure and also make the enclosure ready for disaster preparedness.
