Video Mount Product Rack Shelves

Video Mount Product Rack Shelves

Durable Shelving Solutions for Every Setup

This versatile line of rack shelves are designed to enhance organization, airflow, and accessibility in racks and enclosures, including:

Rack Mounted Sliding Shelf 1U (ER-SS1IU): 1U sliding rack shelf for keyboards and similar equipment. Comes with #10-32 and #12-24 screws. When inverted, can be used as a storage drawer.

Vented 1U Adjustable Four Post Rack Shelf (ER-S1U4P): Vented one space rack shelf for four post equipment racks. Can accommodate four post racks with depths ranging from 14.75" to 25" deep. Maximum tray width is 17.4 inches, and load capacity is 200 lbs. #10-32 and #12-24 rack screws that attach to the shelf are included.

Vented 1U Rack Shelf (ER-S1UV): Vented one space rack shelf stores components up to 17.375" wide and 14.75" deep. Features a 50 lbs. load capacity, and includes #10-32 and #12-24 rack screws.

Economy Rack Shelf (ER-S1): Two space economy rack shelf offers a durable 40 lb. load capacity, and features two sets of mounting screws.

Vented 2U Rack Shelf (ER-S2UV): Vented two space rack shelf that stores components in space up to 17.375" wide and 14.75" deep. With a load capacity of 50 lbs., both #10-32 and #12-24 rack screws attach to the shelf.

2U Rack Shelf (ER-S2U): Two space rack shelf that stores components up to 17.375" wide and 14.75" deep. With a load capacity of 50 lbs., it includes both #10-32 and #12-24 rack screws.

Vented Economy Rack Shelf (ER-S1V): Vented two space rack shelf stores components up to 17" wide and 12.5" deep. With a load capacity of 40 lbs., both #10-32 and #12-24 rack screws can attach to the shelf.



$184.00
$184.00 $184.00
Sale Sold out

Part Number: VMP-ER-SS1U-EA

What's Special

Choice of Configurations: From economy fixed shelves, to vented shelves, to sliding shelves, there is something to optimize every rack.

Rack-Ready Builds: Achieve professional rack deployment effortlessly, with #10‑32 and #12‑24 screw sets, tie-down slots, and a sleek, static-resistant black finish.

Flexible Installation: Ideal for dynamic environments with evolving hardware, the adjustable and sliding variants adapt to different equipment sizes and usage needs.

Consistent Quality and Durability: Equipment is constructed from sturdy powder-coated steel for reliable load support and long-term resistance to wear, keeping equipment organized and secure.

Features

For ER-SS1IU:

  • Shelf closes flush when not in use.
  • Shelf “locks” into place when fully closed, which prevents drifting.
  • Maximum extension is 13.8”.
  • Tray dimension is 16.3” W x 13.8” D x 1.75” H (1 RU).
  • Comes with optional (included) 4 post mounting ears adjust – 17.5” - 20”.
  • When inverted, can be used as a storage drawer.
  • 10-32 and 12-24 mounting screws are included.
  • Load capacity is 35 lbs.
  • Made with a black static resistant powder coat finish.

For ER-S1U4P:

  • Fits components up to 16.85” wide (17.4” when shelf is flipped over).
  • Racking height is 1U (1.75”).
  • Depth of tray is adjustable from 14.75” to 25”.
  • Comes with #10-32 and #12-24 rack screws.
  • Load capacity is 200 lbs.
  • Features a black static resistant powder coat finish.

For ER-S1UV

  • Designed for components up to 17.375” wide.
  • Racking height is 1U (1.75”)
  • Tray depth is 14.75”.
  • Comes with convenient tie down slots in rear of tray.
  • Includes #10-32 and #12-24 rack screws.
  • Load capacity is 50 lbs.
  • Features a black static resistant powder coat finish.

For ER-S1:

  • Fits components up to 17” wide.
  • Two space racking height is 2.6".
  • Tray depth is 12.5”.
  • Comes with #10-32 and #12-24 mounting screws.
  • Load capacity is 40 lbs.
  • Features a black powder coat finish.

For ER-S2UV

  • Made for components up to 17.375” wide.
  • Racking height is 2U or 3.5”.
  • Tray depth is 14.75”.
  • Convenient tie down slots situated in rear of tray.
  • #10-32 and #12-24 rack screws included.
  • Load capacity is 50 lbs.
    Black static resistant powder coat finish.

For ER-S2U

  • Fits components up to 17.375” wide.
  • Racking height is 2U or 3.5”.
  • Tray depth is 14.75”.
  • Convenient tie down slots located in rear of tray.
  • Includes #10-32 and #12-24 mounting screws.
  • Load capacity is 50 lbs.
  • Comes with black static resistant powder coat finish.

For ER-S1V

  • Fits components up to 17” wide.
  • Equipped with two space racking height of 2.6”.
  • Tray depth is 12.5”.
  • Includes both #10-32 and #12-24 mounting screws.
  • Load capacity of 40 lbs.
  • Made with a black powder coat finish.
