Tripp Lite Digital UPS Systems
Tripp Lite Digital UPS Systems
A UPS is an uninterruptable power supply system that provides backup power for your components in the event that you experience a blackout, brownout, surge or other unexpected electrical event. With the combination of a microcontroller unit (MCU) and digital signal processor (DSP) in a single chip, these digital UPS’s from Tripp-Lite allow higher performing power protection at a much lower cost.
Part Number: TL-OMNI650LCD-EA
Couldn't load pickup availability
What's Special
What's Special
- Provides voltage regulation, surge suppression and long-life battery support for personal computers, home entertainment systems and media center.
- Large easy to read backlit LCD input voltage display rotates so it can be read in the horizontal or vertical position.
Features
Features
Traditionally, UPS systems have been designed as analog circuitry, however with the growing technology, digital UPS's are becoming more of a preference.
Equipped with Automatic Voltage Regulation (AVR) technology to prevent viewing interruptions and the loss of critical data, lost recordings and component programming.
Includes workstation and home theater optimized features such as USB & serial ports, single line TEL / DSL or ethernet line surge suppression.
HID-compliant USB interface allows for interface with built-in power management and auto shutdown features of Windows and Mac OS X.
Built-in audible alarm and large LCD front panel voltage display indicates line power status, battery power status, battery low/replace status and voltage boost operation.
Power protection encased in an attractive black tower configuration
Input: NEMA 5-15P (120V 15A) / Output: 8 NEMA 5-15R (120V)
2 year manufacturer's warranty / $200,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Applications:
Entry-level PCs
Networked workstations
Point-of-sale equipment
Small business phone systems
Audio/video equipment
Home theater systems
Sensitive electronics
Model OMNI650LCD OmniSmart Digital UPS
Offers 3.5 min. battery runtime with a full load of 650VA/350W and 12 min. with a half load of 325VA/175W. Maintains 120V nominal output over an input range of 89 to 132V.
Supports entry-level PCs up to 40 min. or single VCR/DVR components for up to 2 hours during blackouts.
Regulates brownouts as low as 89V back to usable levels without consuming battery power.
4 UPS battery-supported/surge-protected outlets plus 4 additional surge suppression-only outlets.
Package Includes:
OMNI650LCD Digital UPS System
Manual with warranty information
Model OMNI900LCD OmniSmart Digital UPS
Offers 3 min. battery runtime with a full load of 900VA/475W and 10 min. with a half load of 450VA/237W. Maintains 120V nominal output over an input range of 89 to 132V.
Includes 4 battery-supported and surge-protected outlets, plus 4 additional surge suppression-only outlets.
Supports battery replacement via built-in access panel.
Supports entry level PCs up to 50 minutes or single VCR/DVR components for up to 2.5 hours during blackouts.
Package Includes:
OMNI900LCD Digital UPS System
Manual with warranty information
Model SMART1000LCD SmartPro Digital UPS
Offers 3 min. battery runtime with a full load of 1000VA/500W and 9 min. with a half load of 500VA/250W. Maintains 120V nominal output over an input range of 89 to 132V.
Includes 4 battery-supported outlets, plus 4 additional surge suppression-only outlets.
Set of 2.2 GHz coaxial jacks protect against surges entering on CATV, satellite or broadcast antenna connections.
Supports entry level PCs up to 60 minutes or single VCR/DVR components for up to 3 hours during blackouts.
Package Includes:
SMART1000LCD Digital UPS
USB and phone cabling
Manual with warranty informatio
Model SMART1200LCD SmartPro Digital UPS
Offers 4 min. battery runtime with a full load of 1200VA/700W and 12 min. with a half load of 600VA/350W. Maintains 120V nominal output over an input range of 75 to 147V.
Includes 8 battery-supported outlets
Built-in USB and DB9 serial ports enable optional unattended system shutdown without data loss in case of extended power failure; cabling included.
Set of phone/network protection jacks protects a single dialup/DSL phone line or network Ethernet connection.
Package Includes:
SMART1200LCD Digital UPS
USB, DB9 and phone cabling
Mounting hardware
Manual with warranty information
Model SMART1500LCD SmartPro Digital UPS
Offers 3.5 min. battery runtime with a full load of 1500VA/900W and 13 min. with a half load of 750VA/450W.
Includes 8 battery-supported outlets
Included DB9 serial and USB monitoring port and cable enable unattended shutdown in the case of extended power failure.
Package Includes:
SMART1500LCD Digital UPS
USB and phone cabling
Mounting hardware
Manual with warranty information
Specifications
