Signamax 10/100/1000 Gigabit Switching Media Converter

Signamax 10/100/1000 Gigabit Switching Media Converter

The Best Solution for Simple or Advanced Gigabit Ethernet Networks

Media converters from Signamax Connectivity Systems are an easy and cost effective way to establish fiber optic infrastructure within your existing legacy 10BaseT or 100BaseTX network to the more advanced gigabit 1000BaseT Ethernet networks.

$531.56
$531.56 $531.56
Sale Sold out

Part Number: SX-065-1196A-EA


Name: Signamax 10/100/1000 to 1000SX MM/SC 220m 62.5micron/550m 50micron Converter

$531.56
$531.56 $531.56
Sale Sold out
  • Cost effective way to establish a fiber optic cabling infrastructure.
  • Built-in twisted pair 10/100/1000 switch
  • Fiber connection operates at 1000 Mbps and can operate in full duplex mode.
  • It can be used as a stand alone wall device or placed in a 19" chassis.

The Signamax 10/100/1000 switching media converter has a built in 10/100/1000 switch that allows the fiber connection to operate at 1000Mbps when connected to a 10BaseT or 100BaseTX network and still remain compliant to fiber optic networks of 1000BaseSX. The RJ45 port can be connected to a full duplex switch or half duplex hub and still operate in full duplex mode. The built-in switch provides for maximum fiber connectivity and distance.

  • One channel media conversion between 10/100/1000 Base TX and 1000Base SX/LX
  • Built-in twisted pair port 10/100/1000 switch
  • Available in multi mode (SC) with 220m distance capability.
  • Converter is equipped with 6 front panel status LEDs for functions, links, and activities.
  • Store-and-forward switching mechanism
  • Full and half duplex operation
  • External AC to DC power adapter is included
  • Complies with IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.3ab 1000BaseT, IEEE 802.3Z 1000BaseSX, and IEEE 802.3Z 1000BaseLX Ethernet standards
  • UL LIsted
  • Use as a stand alone device or within a chassis (ordered separately)
  • Hot swappable when used with a chassis
  • Wall mountable
  • Lifetime performance guarantee from Signamax Connectivity Systems
