Middle Atlantic ERK Stand-Alone Enclosures

Middle Atlantic ERK Stand-Alone Enclosures

Design The Perfect Enclosure For Your Needs

Middle Atlantic's new line of ERK Stand-Alone Enclosures provide you with several different options when it comes to size, doors, casters, ventilation, rails, and cooling. For users who need a quick answer to their needs, with all the essentials needed for getting started, the ERK series also provides a line of ready to use preconfigured enclosures.

$674.10
$674.10 $674.10
Sale Sold out

Part Number: QMA-ERK-1820-EA

What's Special

  • High quality with a large range of customizable options and accessories, for creating an unique enclosure tailored around meeting your specifications and needs.
  • Fully welded construction is reinforced with 1/8" structural steel internal braces to provide the highest quality in structural support, even under full loads.
  • Grounding and bonding studs are preinstalled into the base to help you electrically ground and bond equipment, per NEBS and NEC standards.

Features

  • Finished in a durable black textured powder coat to protect your enclosure and keep it looking stylish for years to come.
  • Durable steel construction withstands equipment loads of up to 2,500 lbs.
  • One pair of 10-32 tapped, front-mounted and fully adjustable rails are included for safely securing media and network components, with optional rear mounting rails available.
  • Provides 1/2", 3/4", 1" and 1-1/2" electrical knockouts on removable split rear plates, with additional UHF/VHF antenna knockouts on the top plate.
  • Extra large opening on the bottom for cable entry and easy routing.
  • 18, 21 and 27RU enclosures come with a solid preconfigured top, with two 4.5" fan knockouts for easy cooling installation and options.
  • Large range of solid, vented or preconfigured fan tops available for 35, 40 and 44RU enclosures.
  • 35, 40 and 44RU enclosures provide laser cut knockouts in side panels for easy ganging and cable pass-through.
  • Commercial grade caster bases are equipped with 3" diameter swivel wheels which have a weight capacity of 1,300 lbs.
  • New, fine floor caster bases are available with 3" diameter swivel wheels. Made from Dynatread TPR, these casters protect against damaging decorative flooring, and have a weight capacity of 700 lbs.
  • Seismic certified for protecting 650 lbs. of essential equipment when used in conjunction with ERK-Z4 brackets- UBC 1997 & CBC 1998 Zone 4; IBC 2000, IBC 2003, ASCE 7 - 02, NFPA 5000 Seismic Use Group III.
  • cULus listed (enclosures)- File number E173107
  • cULus listed (fan and door assembly)- File number E252615
  • EIA/TIA Compliant
  • RoHS Compliant
  • Proudly made in the USA

Specifications

Middle Atlantic ERK Stand Alone Enclosures
