Middle Atlantic DWR Series 19" Wall Mount Rack
Middle Atlantic DWR Series 19" Wall Mount Rack
If floor space is limited and you are installing a larger system, the Middle Atlantic pivoting sectional wall mount cabinet with enhanced cable management features will work perfectly in both secure and none secure environments. This cabinet is manufactured in multiple sizes with extraordinary cable management features. It’s time saving Tool Free Quick Mount system allows for one person to easily mount the center section to the backpan. The DWR wall mount rack cabinet is one of the most versatile and durable cabinets available anywhere. Reversible padlock-able center section and an optional front door is keyed differently for added security.
Part Number: MA-DWR-10-17PD-EA
Couldn't load pickup availability
What's Special
What's Special
- UL listed in the US and Canada, EIA/TIA Compliant
- Welded 16-gauge steel construction with 1/8” thick laser cut corner braces
- Available in 17” Depth, 22” Depth and 26” overall depths with 15”, 20” and 24” useable depths
Features
Features
- The Zero Clearance Latch option allows side-by-side or interior corner mounting.
- Load Capacity: Up to 300 lbs depending on the model
- Unique dual pivot of the center section hinges allows for left or right opening without disassembly.
NEW! Tool Free Quick Mount System™ allows the installer the ability to easily mount the center section to the backpan on the jobsite by himself.
- Standard adjustable front 11-gauge, 10-32 threaded Rackrails with marked rack space increments to speed equipment mounting and e-coat finish.
- Available in BLACK textured powder coat finish
- Lifetime Warranty from Middle Atlantic Products
- Proudly made in the USA
Cable Management Features:
- The rack swings open for component cable access with outstanding cable lacing features.
- 1/2”, 3/4”, 1”, 1-1/2”, 2” and 3” electrical knockouts on top and bottom.
- Four cutouts for low voltage Decora® devices and RPS series remote power switch in front and rear section, top and bottom.
- Top knockout plate additionally contains UHF/VHF antenna knockouts.
- Extensive lacer points throughout the interior of the cabinet to facilitate cable management.
- Large laser knockout in the backpan provides an easily removable 12-1/2” x 12-1/2” pull box sized opening for cable passage.
- Grounding/bonding studs in top and bottom center section and backpan to facilitate proper grounding and bonding of electrical equipment per NEBS and NEC standards.
Optional ACCESSORIES:
- Zero Clearance Latch: allows side-by-side or interior corner mounting.
- Fan Kits: Fan knockouts on top and bottom allow for installation of up to four 4 1/2” fans.
- Additional Threaded Rackrails
- Optional Front Doors
- Power Strips and Power Distribution Brackets required for mounting vertical power strip
Specifications
