IGUS® Chainflex® CF5 Economy Non-Shielded PVC Control Cables

IGUS® Chainflex® CF5 Economy Non-Shielded PVC Control Cables

Affordable Yet Rugged Solution for Wiring Heavy Automated Machinery

Today’s hard working and fast paced robotics, computerized tools, and automated machinery require strong and highly flexible cabling. Other brands of control cables can be very expensive to purchase yet still have the disadvantages of being prone to breakdowns, the the quick deterioration under the constant stress and friction. IGUS®, a world leader in moving cable management, introduced their new line of Chainflex® cables specially designed to withstand the grueling rigors of today’s heavy machinery. The Chainflex® CF5 line of economy PVC Control Cables offer installers and machine operators with an affordable wiring solution that is abrasion-resistant, oil-resistant, UV-resistant and flame-retardant.

  • RoHS Compliant
  • CE
  • UL
  • CSA Approved
  • UL Recognized Component Mark
$8.63
$8.63 $8.63
Sale Sold out

Part Number: IGU-CF5-02-36-EA


Name: IGUS-Chainflex CF5 Economy PVC Control Cable, 24 AWG, 36 Conductors, Per Foot-Green

$8.63
$8.63 $8.63
Sale Sold out
  • Durable and resistant construction withstands the constant friction and abuse associated with moving machinery or cable/hose carrier systems, while remaining affordable enough for budgeted applications.
  • Braided conductors are layered in short pitches around a high tensile strength strain-relief core, providing extremely low torsion and greatly reducing stress when subjected to fast paced flexing and motion.
  • Available in a large range of AWG and conductor combinations that are cЯUus and CE rated for meeting building, equipment, or safety requirements.

Finely stranded conductors are made from bend-resistant bare copper wires in accordance with EN 60228, for providing excellent performance in high mechanical load requirements.

Individual conductors are coated in a high-quality, mechanical grade PVC-insulating compound to protect bare copper from corrosion prior to installation and reducing crosstalk after termination.

Durable outer jacket is made from an oil-resistant, PVC-based blend that has been adapted to the rigors and frictions found inside cable/hose carrier systems.

Outer jacket is Silicon-free in compliance with PV 3.10.7 – status 1992.

Flame rating FT1

RoHS compliant

cRUus rated

CE rated

Versatile construction is ideal for a wide range of applications:

Light oil influence

Indoor applications, or can be used in outdoor applications with temperatures > 23°F

Storage and retrieval units for high-bay warehouses

CNC and milling machinery

Packaging machines

Indoor cranes

EU Data sheet chainflex CF5 IGUS Chainflex CF5 Economy Non Shielded PVC Control Cables
