Great Lakes Four Post Open Relay Rack

• 84" high and 20.6" wide
• 45 rack mount spaces
• Four (4) depth sizes available to accommodate your needs
• 1,500 lb weight capacity, made of sturdy 12 gauge steel
• Mounting hardware included

• 45 rack mount spaces
• UL60950-1 Listed Standard for IT & Communications Equipment, Cabinet Enclosures and Rack Systems
• All assembly and mounting hardware is included with a choice threaded mounting using 50 12/24 type screws or 50 M6 universal mounting cage nuts and screws
• Toe in or toe out mounting option as shown on specification
• 19" EIA 310-E Mounting compliant
• UL 2416
• Four Post Rack with 12/24 threaded mounting is manufactured as black anodized aluminum with 2 gauge steel brackets
• Four post rack with Universal mounting M6 cage nuts and screws is made of 12 gauge cold rolled steel painted in black durable powder coat
• Ships unassembled in 3 packages yet easy to assemble.
• Racks are gangable with GLRR-1984 series 2 post racks
• Full factory warranty from Great Lakes Case & Cabinet Co. Inc.
• Proudly made in the USA at Great Lakes 9001:2000 Quality certified factory.

 Vertical Cable Manager (1984-VCM10) Features:

• Dimensions: 7' Height x 10" Deep
• Offers cable runs of 6" wide x 5" deep.
• Front and rear cable runs

Power Strip Mount Bracket (PSBGLRR) Features:

• Compatible with any Great Lakes aluminum relay rack and four post rack
• Allows you to mount US voltage 7215 series of vertical power strips
• Hardware included: (2) 10/32 x 1/4 flat head screw; (4) 12/24 pan head type 23 screws; (4) M6 cage nuts; (4) M6 screws-12mm

 Front Mount Support Bracket (FMSBKT) Features:

Supplies additional support for any front mount equipment

A pair of brackets offer a weight capacity of 100lbs; use of bracket set in front and rear will hold equipment up to 200 lbs
