Fox 2 & Hound 3 Digital Tone Generator Kit

• Adjustable volume / sensitivity control.
• Conductive Duck-Bill Tip for safe, easy penetration in cable bundles. Metal tip also included.
• LED gets brighter as the signal gets stronger.
• Two tone generator contains a high-gain, hi-impedance amplifier.
• Low voltage tone generator is capable of identifying any of the Fox's tone up to 12" away
• Rugged, moisture resistant, mylar cone speaker
• Use with the Fox, Fox2, or Wiremaster XR-2 tone generators for quick and efficient wire tracing
• Powered by a standard 9V battery (not included) with an easy access door.
• 1-year limited manufacturer warranty

Fox 2 Deluxe Tone Generator with "True Trace"

• "True Trace" - Cadence of tracer tone changes when pair is momentarily shorted, allowing for definite ID of target wire pair.
• Cordless phone interface - allows user to use a standard cordless phone for hands-free "True Trace"!
• "Trip-Latch", a unique latch testing technique using "True Trace" for testing alarm sensors.

3 methods of connectivity:
RJ-11 plug for tracing telephone wires,
RJ-45 jack for tracing LAN cables (trace BNC cables w/ optional RJ-45 to BNC adapter),

• Alligator clips on DTMF tone generator allow for connection to stripped wires or terminal panels.
• Overload protected - 120 VAC line cross protection on all functions
• Overload warning beeper - alerts user to potential hazards
• Warble/pulse tracer tone - selectable tone for audible & visual ID using Hound or Hound 2 probe inductive tracer.
• High output tracer tone
• Generates 2 of 6 user selectable tracer tones
• Internal user selectable settings - Hi/Lo pitch shift, warble/continuous tracer tone, On/Off audio pilot tone, On/Off cadence shift.
• Tone/battery LED - indicates that tracer tone is on and battery is OK
• Audio pilot tone - confirms the tracer toner signal
• Visual & audible continuity test
• Red/Green telephone line polarity LEDs - also indicates AC/ RING signal
• Supplies "talk power" to allow communicating between handsets(talk sets) or powering a telephone
• Line powered in ton mode
• Built-in telephone ringer
• "Power Latch" - prevents accidental turn-on's maximizing battery life
• Magnetic back - sticks the Fox 2 to steel surfaces
• Works with either Hound or Hound 2 Probe Inductive Tracer
• Powered by standard 9V battery (not included)
• 1-year limited manufacturer warranty

Hound 3 Probe

• New headlights to help light your way in dark areas and reduce florescent light noise.
• Streamlined design allows for better access in hard-to-reach areas.
• New shielded design to suppress "feedback squeal"
• Band-pass filter to suppress 60Hz and hi frequency noise.
• Earphone jack for use in quiet or noisy environments
• Improved sensitivity and loudness
• Includes new conductive duck-bill tip for safer, easier penetration in cable bundles - metal tip also included
• Easy access battery door
• Adjustable volume / sensitivity control
• LED gets brighter as the signal gets stronger - LED indication even works when earphones are used
• Contains a hi-gain, hi-impedance amplifier
• Capable of identifying the Fox's tone up to 12 inches away
• Rugged, moisture resistant, Mylar cone speaker
• Use with the Fox 2, Fox, Fox Jr., TDR, LAN TDR or WireMaster XR-2 for quick & efficient wire tracing.
• Powered by a standard 9V battery (not included)
• 1-year warranty
