3M™ FireDam™ Spray 200

3M™ FireDam™ Spray 200

An Extra Measure of Protection for Many Applications

FireDam™ Spray 200, a faster drying firestop, is perfect for sealing head of wall, floor to wall, penetration seals, and perimeter joints between fire-rated floors (concrete, fireproofed fluted steel decks) and fire-rated walls (gypsum, concrete). With just 1/8 inch (3mm) coating, it will help control the spread of fire, heat, smoke, noxious gas and water before and during exposure to fire. Application is simple, using conventional airless sprayers. The coating dries under ambient conditions to a neutral gray color and the joints are flexible to allow for compression and extension of up to +/- 25% of nominal joint width.

$381.34
$381.34 $381.34
Sale Sold out

Part Number: FP-3MFDS-EA

Certifications
  • UL Classified

What's Special

  • High-cling properties help prevent sagging
  • Applied with conventional airless sprayers
  • Cleans easily with water (no solvents required)
  • Superior adhesion to most construction materials

Features

Always a leader in fire protection and firestop systems, 3M has added FireDam Spray 200 to its impressive list of firestop products. FireDam™ Spray 200 is UL and Intertek listed. The coating meets ASTM E 1966 and UL2079 specifications for fire testing at the maximum joint width. This product has been cycled to meet the wind sway and thermal category of ASTM E 1399. The coating has also meets through penetration criteria as evaluated by ASTM E 814 and UL 1479. It also complies with IBC, ICC, BOCA, ICBO, SBCCI and NFPA Code #101. Tested for up to 4 hours.

Fast drying

Dries to a neutral gray color

Highly elastic

Paintable when cured

Available in five-gallon pails

90 day warranty

UL Classified, Factory Mutual, and Omega Point Laboratories listed

FM approved (FMRC Approval Guide)

Complies with IBC, ICC, BOCA, ICBO, SBCCI and NFPA Code #101

Meets fire testing criteria of ASTM E 1966 and UL2079 at maximum extended joint width

Meets wind sway cycle and thermal category of ASTM E 1399 (500 cycles at a minimum of 10cycles per minute)

Meets ASTM E 814 and UL1479 for through penetrations

Specifications

FireDam specs 3M FireDam Spray 200
