Tripp Lite SmartRack™ Premium Enclosures

• Strength, sturdiness, and the ability to handle a lot of weight makes these an invaluable part of your IT component housing system.
• Sizes range from 25U to 48U for 25 to 48 spaces of rack mount storage.
• Made from long-lasting black steel, and coated with textured powder coat finish to protect from corrosion and deterioration.

• Each unit is equipped with 1.8" diameter casters for easy portability.
• Equipped with levelers to achieve flat results in uneven environments.
• Built-in versatility with both top and bottom cable access openings.
• Compatibility with air management accessories.
• 3000 lbs. stationary/2250 lbs. rolling load capacity.
• Massive front to rear ventilation capacity.
• 5-year repair or replacement warranty from manufacturer.

There is a complete line of accessories available to customize your enclosure to your specific needs. Easy to install and built to last, these accessories are the perfect addition to your racks.

25U SmartRack Enclosure

Model #SR25UB- Includes doors and side panels

• 25U enclosures include locking, removable and reversible front doors and side panels
• (4) Interior vertical posts with unthreaded square hole openings
• Ships fully assembled

Model #SR25UBSP1- Includes doors and side panels,
ships with shock pallet packaging

• Same features as Model #SR25UB, but ships with special shock pallet packaging to support more weight
• Enables safer loading and re-shipping
• Shock-pallet supports up to 1250 lbs. (281 lbs Enclosure weight + up to 969 lbs of additional equipment)
• Heavy-duty ramps (included) allow enclosure to be rolled on and off the pallet during configuration

42U SmartRack Enclosure

Model #SR42UB - Includes doors and side panels

• 4 interior vertical posts with unthreaded square hole openings
• Ships fully assembled
• Maximum usable internal depth of 37"/94 cm (front to rear rail)
• Locking, reversible and removable front door
• Locking, removable side panels
• Locking, removable split rear doors

Model #SR42UBEXP - Doors only

• Same features as Model #SR42UB SmartRack enclosure, without side panels
• EXP version is an expansion model for when several cabinets are bayed together

Model #SR42UBSP1 - Includes doors and side panels;
ships with shock pallet packaging

• Same features as Model #SR42UB SmartRack enclosure, but ships with special shock pallet packaging to support more weight
• Enables safer loading and re-shipping
• Shock-pallet supports up to 1250 lbs (281 lbs. Enclosure weight + up to 969 lbs. of additional equipment)
• Heavy-duty ramps (included) allow enclosure to be rolled on and off the pallet during configuration

48U SmartRack Enclosure

Model # SR48UB - Includes doors and side panels

• 4 interior vertical posts with unthreaded square hole openings
• Ships fully assembled
• Maximum usable internal depth of 37"/94 cm (front to rear rail)
• Locking, reversible and removable front door
• Locking, removable side panels
• Locking, removable split rear doors

Panels

Model #N252-012 - 12-Port Cat6 Patch Panel
Model #N252-024 - 24-Port Cat6 Patch Panel

• For use with Cat6 Cable
• Choose 12 or 24 port panels for a wide range of plug-n-play options
• 110-type termination
• EIA/TIA TSB-40 Cat6 connecting hardware specifications
• Color coded for EIA/TIA 568A & 568B installations
• Ports clearly numbered both on front and back
• Labels on front enable each port to be named
• Metal frame
• EIA/TIA 2/32 spacing
• Mountable on a 19" rack (1U of space)
• High Density 19" rackmount ready panel design saves space
• Warranted to be free from defects in materials and workmanship for life

Model #N052-012 - 12-Port Cat5e Patch Panel
Model #N052-024 - 24-Port Cat5e Patch Panel

• For use with Cat5e Cable
• Choose 12 or 24 port panels for a wide range of plug-n-play options
• 110-type termination
• EIA/TIA TSB-40 Cat5e connecting hardware specifications
• Color coded for EIA/TIA 568A & 568B installations
• Ports clearly numbered both on front and back
• Labels on front enable each port to be named
• Metal frame
• EIA/TIA 2/32 spacing
• Mountable on a 19" rack (1U of space)
• High Density 19" rackmount ready panel design saves space
• Warranted to be free from defects in materials and workmanship for life
