Great Lakes Compact E Series Enclosures

• Versatile design provides full scale mounting options and equipment protection, in an economical size that is ideal for a wide range of applications with space limitations.
• Complete 30”, 48” or 60” high enclosures with a variety of accessories, doors, side panels, and top panels available for allowing for customization and design options.
• Fully welded steel construction has increased weight capacity for mounting and storing heavy networking and telecommunications equipment.

• Universal M6 rails for mounting a wide range of accessories, patch panels, and cable management solutions.
• Horse shoe style cutouts on top panel for easy pass through cable management, while allowing you to change or remove top panel without interfering with preexisting cable bundles.
• Fully reversible doors for accommodating limited spacing, equipment specifications, or preexisting racks/enclosures.
• Lockable side panels for increased security and equipment protection.
• Mounting rails feature built-in cable management holes and cable tie-down slots, with infinitely adjustable positions.
• Networkable for medium and large scale applications.
• Multiple ground stud locations
• 19” EIA 310-E compliant
• cULus listed UL 60950-1
• RoHS compliant

Includes:

QGL-300E-2432

• Enclosure frame with two 2 pair of black powder coated, universal M6 19" mounting rails and package of M6 hardware
• One set of 4 Adjustable Levelers (2.50" H)
• Plexiglas front door with locking swing handle
• Perimeter vented steel rear door with locking swing handle
• Pair of solid lift-off side panels with lock
• 6 position, 15 amp Power Strip with circuit breaker and 15 ft. cord for 19" mounting
• Removable top panel (varies per model)

QGL-480E-2432

• Enclosure frame with two 2 pair of black powder coated, universal M6 19" mounting rails and package of M6 hardware
• One set of 4 Adjustable Levelers (2.50" H)
• Plexiglas front door with locking swing handle
• Perimeter vented steel rear door with locking swing handle
• Pair of solid lift-off side panels with lock
• 6 position, 15 amp Power Strip with circuit breaker and 15 ft. cord for 19" mounting
• Removable top panel (varies per model)

QGL-600E-2432:

• Enclosure frame with two 2 pair of black powder coated, universal M6 19" mounting rails and package of M6 hardware
• One set of 4 Adjustable Levelers (2.50" H)
• Plexiglas front door with locking swing handle
• Perimeter vented steel rear door with locking swing handle
• Pair of solid lift-off side panels with lock
• 6 position, 15 amp Power Strip with circuit breaker and 15 ft. cord for 19" mounting
• Removable top panel (varies per model)
