Bridle Rings for Low-Voltage Cable Support

• Supports and manages all low-voltage cables, including UTP, fiber optics, and electrical wire up to 600V.
• Cables are placed into the ring through an open slot on the top for a simple and stress-free installation.
• Since these bridle rings form a full circle, they may be used for horizontal or vertical wire runs, unlike J-hooks.
• Can be used on walls and ceilings, making them ideal for multi-directional cable runs.

• Zinc-plated steel construction for great durability and corrosion resistance.

4 mounting types available to accommodate your varying installs:

• Wood screw bridle ring drives directly into wood with no tools, clamps, or fasteners necessary, for a quick and easy installation.
• 10-24 (1/4-20) machine thread bridle ring can be used with 10-24 threaded clamps or supports.
• Toggle Wing head (requires drilling) is used for mounting cables onto a hollow wall.
• Non-Threaded cable support rings are best for applications where drilling is undesired.

2 support options for safe cable-specific handling:

Standard, no saddle: a cost effective option that is suitable for cables ranging from Cat 5/5e/6a to electrical cables up to 600V.

Saddled Ring: contains a supportive platform for bend-sensitive cables such as fiber optics and Category 7.
