Bonito® USB In-Desk Power Outlet

A power and USB charger that fits snuggly into a pre-cut hole in your desk for added connectivity.


WR-TL-HOLESAW-425
Qty:

What's Special about this Power and USB Desk Outlet?

  • 3 AC power outlets
  • 2 USB ports with 2.4A at 5V combined power
  • Discreet flip-over cover to conceal and protect the outlets
  • Fire retardant ABS construction
  • Adds connectivity to your desktop
  • Click for More Features
  •
  • RoHS CompliantULUL Classified

Combining power and USB charging capabilities, the WireRun® Bonito® Power and USB Desk Outlet adds connectivity to your desktop. It is great for working with numerous applications at once, while still having power available. Installation is easy and can be completed by one person by simply cutting a 4.21 inch hole into a solid surface. This desk outlet easily flips over, providing outlets and connectivity when you need it, and hiding the outlets when you don't. There is an 8-foot power cord that is included so that you can easily access a wall outlet right from your desk.

Bonito® USB In-Desk Power Outlet Grommets
Part # Description Ports Color Price
WR-BONITO-PPPXX-96 Bonito® Outlet Power Grommet 3 Power & 2 Powered USB Black, White
Qty:
Quick Ship
WR-TL-HOLESAW-425 4.25” Hole Saw - White
Qty:
Manufacturer Direct
Curated Kits
Part # IMG Description Contents Price
WR-BONITO-INSTALL-KIT Wirerun Bonito Desk Outlet Install Kit Wirerun Bonito Desk Outlet Install Kit
Qty:
Manufacturer Direct
  • 3 AC power outlets (NEMA 5-15R)
  • 2 USB charging ports with combined output of 2.4A at 5V
  • Discreet flip-over cover to conceal and protect the outlets
  • Fire retardant ABS construction
  • Adds connectivity to your desktop
  • Includes an 8-foot power cord
  • When not in use, it sits flush with the table
  • Great for many different applications and environments like the home or office.
  • Grounded for proper electrical safety
  • 5 year limited warranty
  • dimensions for Grommet

    PART# DESCRIPTION A B C D E
    WR-BONITO-PPPXX-96 Bonito® Power Grommet with 3 Power / 2 Powered USB 4.44" (112.7 mm) 3.69 (93.7 mm) 1.13" (28.7 mm) 4.21" (106.9 mm) 1.25" (31.7 mm)



    PROPERTY VALUE
    Power 15A /125V
    60 Hz
    1875W
    USB Powered USB 2.4
    Temperature Operating: 32°F to 131°F (0 to 55° C)

    Storage: 5°F to 149°F (-15 to 65° C)
    Relative Humdity Operating: 0 to 80%

    Storage: 0 to 80%
    Elevation Operating: 0 to 10,000 ft (0 to 3,000 m)

    Storage: 0 to 50,000 ft (0 to 15,000 m)
    Material Fire Retardant ABS
    Industry Standards UL E309585
    Patent Number US 6,969,800 B1







    Manuals



    Related Articles







    How-To Corner







    Assembly Instructions:
    1. Determine the grommet placement on your desk or table top. Use a template as a guide for a hole saw or jig saw. Tape the pattern to the top.
    2. Drill a hole in the center of the template large enough to start cutting. Closely follow the circle perimeter with the jig saw blade.
    3. Feed the power cable through the hole first and then seat the grommet in place. If the grommet is a little loose for the hole, use some glue or cememt to hold the grommet in place.
    4. Plug the power cord into a wall outlet and it is ready for use. Slide tab back to enable pivoting of the PowerTap. When rotation is complete it will lock in place.

    Request A Quote

    Did you know that we can give you a quote for most of our products, including shipping?

    You can also call us toll free 1-833-3CABLEORG (1-833-322-2536)

    Questions & Answers

    Question:

    What is the power output in amps on the 2 USB ports?

    Asked by Anonymous user on 11.11 AM Monday, 07 November, 2016

    Answer:
    • - Thank you for your question. The USB Ports have a combined output of 2.1A at 5V. Please give us a call if you have any other questions or to place an order.

      Anonymous user on 04.52 PM Friday, 27 January, 2017
    Question:

    Do you have a model with 1 USB and 1 cat5 port

    Asked by Anonymous user on 01.34 PM Saturday, 04 March, 2017

    Answer:
    • - Unfortunately not for this unit however, we do offer other customizable units that can be configured to your specifications. Please call us to discuss and obtain a quote! 866-222-0030

      Anonymous user on 04.45 PM Tuesday, 14 March, 2017
    Question:

    How is this outlet powered after installed into a desk?

    Asked by Anonymous user on 05.20 PM Tuesday, 28 March, 2017

    Answer:
    • - Hello, The Power Grommet has an 8 foot long power cord that can be plugged into any wall outlet

      andrew b. on 05.01 PM Tuesday, 04 April, 2017
    Question:

    can I charge my phone from the usb ports

    Asked by Anonymous user on 03.51 PM Friday, 07 April, 2017

    Answer:
    • - Hello, Yes, you can charge your cell phone or any other device through the 2 powered USB connections.

      andrew b. on 04.36 PM Friday, 07 April, 2017
    Question:

    How long is the cable?

    Asked by Anonymous user on 01.46 PM Tuesday, 25 April, 2017

    Answer:
    • - Hello, The cable is 8 feet long. If you have any other questions please feel free to call us toll free at 866-222-0030

      andrew b. on 10.40 AM Wednesday, 26 April, 2017
    Question:

    I'm needing desk top round receptacle, can you shop overnight?

    Asked by Anonymous user on 07.00 PM Wednesday, 03 May, 2017

    Answer:
    • - Hello, If you place your order before 2pm EST, your order can ship out overnight to you.

      andrew b. on 04.30 PM Thursday, 04 May, 2017
    Question:

    Can the outlet be mounted vertically, or is it for desktop only? I would like to mount this in the side of a desk.

    Asked by Anonymous user on 01.21 PM Saturday, 05 August, 2017

    Answer:
    • - Hello, It's less easy to flip the outlet (open & close) due to the cord, than when it's mounted in a desktop and the cord naturally droops down. It may work if you are able to deal with a more difficult way of using the item.

      andrew b. on 10.03 AM Tuesday, 15 August, 2017
    Question:

    we are planning to use this outlet for a hospitality furniture, which we are selling. do we need any additional UL tests and certification? thank you, Paul

    Asked by Anonymous user on 05.43 PM Friday, 18 August, 2017

    Answer:
    • - Hello, No this is UL E309585 certified

      andrew b. on 10.06 AM Thursday, 24 August, 2017
    Question:

    Are they longer lengths available for the cord?

    Asked by Anonymous user on 02.39 PM Tuesday, 20 March, 2018

    Answer:
    • - Hello, The power cord is only available in 8 foot lengths.

      Anonymous user on 04.08 PM Wednesday, 28 March, 2018
