Panduit Thermal Transfer Desktop Printer

Quickly Create High-Quality Identification Labels

Low Price Guarantee

PAN-TDP43ME



PAN-RMEH4BL



PAN-RMH2BL

What's special about the thermal transfer printer from Panduit?

  • Panduit thermal transfer desktop printer creates high quality labels
  • Compact design enables use in the office or anywhere space is limited
  • 300 DPI thermal transfer creates crisp, clear labels and legible text
  • 4 inches/second print speed allows time and money saving
  • One button operation and auto-sensing gap detection reduces adjustment times
  • Click for More Features

The TDP43ME Thermal Transfer Printer by Panduit® is a small form label printer designed to produce industrial level numbers of high quality labels. With easy to use software, this printer presents itself as a must-have for any operation where making labels is necessary. A great selection of accessories for the Panduit® TDP43ME is also available, to ensure that all angles are covered.

Images

PART # DESCRIPTION WEIGHT PRICE
PAN-TDP43ME Panduit TDP43ME printer, Hybrid Ribbon, Easy Mark Software, AC Power Adapter w/US power cord, USB Cable, User Manual, Quick Start Card, and Driver Disk 10.3 lbs
Qty:
PAN-TDP43ME-E Panduit TDP43ME printer, Easy Mark software, Hybrid black ribbon, EuroPlug cord, USB Cable, User Manual, Quick Start Card, and Driver Disk 11.6 lbs
Qty:
Accessories
PAN-RMEH4BL Replacement ribbon, used for Hybrid, Wax and Resin applications 0.2967 lb
Qty:
PAN-TDP43M-ACY Replacement AC power adapter with power cord (US cord only) 1.5 lbs
Qty:
PAN-TDP43ME-RS External label roll stand for rear feed labels, supplied on 3" cores 1.9 lbs
Qty:
PAN-TDP43ME-CASE Hardside carrying case. Accommodates printer, AC power adapter, ribbons, printer cable, labels and tools 9.8 lbs
Qty:
Panduit Military Grade Polyolefin Heat Shrink Labels
Thermal Transfer Component Labels
Thermal Transfer Marker Plates



Thermal Transfer Ribbons

SKU Description Height Width Length Material PRICE
PAN-RMH2BL PANDUIT® Black Hybrid Thermal Transfer Ribbon 2.52" 2.52" 240 ft Wax/Resin Hybrid
Qty:
PAN-RMH4BL PANDUIT® Black Hybrid Thermal Transfer Ribbon 4.33" 4.33" 240 ft Wax/Resin Hybrid
Qty:

PAN-RMW2BL PANDUIT® Black Wax Thermal Transfer Ribbon 2.52" 2.52" 240 ft Wax
Qty:
PAN-RMW4BL PANDUIT® Black Wax Thermal Transfer Ribbon 4.33" 4.33" 240 ft Wax
Qty:

PAN-RMR2BL PANDUIT® Black Resin Thermal Transfer Ribbon 2.52" 2.52" 240 ft Resin
Qty:
PAN-RMR2WH PANDUIT® White Resin Thermal Transfer Ribbon 2.52" 2.52" 240 ft Resin
Qty:
PAN-RMER4BL PANDUIT® Black Resin Thermal Transfer Ribbon 4.33" 4.33" 240 ft Resin
Qty:
  • Setup and label loading are quick and easy - they take only minutes, for minimal down time
  • Manufactured of durable plastic to withstand the occasional bump or fall
  • Perfect for use on wire, cable, terminal blocks, conduit, control panels, and many other applications in the home, office or construction site



Recommended tape use:

  • Hybrid – Recommended for use with self-laminating, heat shrink, component and non-laminated labels
  • Wax – Recommended for use with self-laminating and non-laminated labels
  • Resin – Recommended for use with component labels, marker plates, and continuous tape



Ideal for printing on:



Resolution 300 dpi (12dot/mm)
Print Mode Thermal Transfer
CPU 32 Bit
Memory  4MB Flash, 8MB SDRAM
Print Speed  2 IPS~4 IPS
Print Length Min 12mm (1.47") Max 762mm (30")
Print Width 105.7mm (4.16")
Sensor Type Adjustable Reflective sensor; Fixed transmissive, center aligned
Sensor Detection Type: Label gap and black mark sensing.
Detection: Label length auto sensing and/or program command setting
Media Label Roll OD: Max. 4.92" (125mm)
Cord Diameter: 1" (25mm), 1.5" (38mm), 3" (76mm)
Width: 1" (25mm) ~ 4.64" (118mm)
Thickness: 0.0025" ~ 0.0098" (0.06~0.25mm)
Ribbon Length: 981 ft. (300M)
Max. Ribbon roll OD: 2.67" (68mm)
Type: Transfer ribbons (wax, hybrid, and resin) in widths of: 1.18" to 4.33" (30mm to 110mm)
Core Inner Diameter: 1" (25.4mm)
Printer Language EZPL Programming Language
Software DLL & Driver: Microsoft Windows 2000 and XP, Vista (32 & 64 bit); Microsoft Windows 7 (32 & 64 bit)
Easy-Mark Labeling Software
Image Handling Support BMP and PCX. Support ICO, WMF, JPG, EMF file through software. Support image resize, rotating, mapping and inverse through software.
Resident Barcodes Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128,UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping
Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, MaxiCode, HIBC, Plessey, Random Weight, Telepen,
FIM, China Postal Code, RPS 128, PDF417, Datamatrix code & QR code
Interfaces Serial port: RS-232 ( Baud rate : 4800 ~ 115200 , Xon/Xoff , DSR/DTR )
USB port: V2.0
Parallel port: Bi-direction Ethernet TCP/IP Port (wireless – optional)
Control Panel Two Bi-color LED: Ready, Status Function Key: FEED
Power Auto Switching 100/240VAC, 50/60 Hz
Environment Operation: 41°F to 104°F (5°C to 40°C)
Storage: -4°F to 122°F (-20°C to 50°C)
Humidity Operation: 30-85%, non-condensing. Free air.
Storage: 10-90%, non-condensing. Free air.
Cert. Approval CE, FCC Class A, CCC, CB, cUL, RoHS, WEEE
Printer Dimension Length: 11.2" (285 mm)
Height: 6.8" (171 mm)
Width: 8.9" (226 mm)
Weight: 6 lbs. (2.72 Kg)





FCC - DECLARATION OF CONFORMITY:

Model: TDP43M conforms to the following specification: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a) Class B digital device

Supplemental Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.



INDUSTRY CANADA NOTICE:

This device complies with Industry Canada ICS-003 class B Requirements. Cet equipment est conforme a l'ICS-003 classe B de la norm Industrielle Canadien.
