EVO6™ Category 6 Self-Tracing LED Patch Cords

Reduces Network Downtime for Increased Productivity

Low Price Guarantee Scroll To Pricing

What's special about these self-tracing ethernet cables?

  • Contains a bright red LED light on each plug that allows you to trace cables instantly in complex wiring systems
  • Dramatically reduces downtime by providing instant cable identification for efficient mistake resolution and maintenance
  • Requires no outside equipment to trace cable; simply press the button on the boot and both ends flash bright red for quick matching
  • Backward compatible with Cat3, Cat5 and Cat5e for easy retrofits or integration with any network component that uses an RJ-45 connection
  • Click for More Features
RoHS CompliantULCE

Many IT installers know the pain of taking several hours to fix a mistake it took a mere 5 seconds to make. The EVO6™ traceable patch cable from Mertek™ employs a bright LED that allows you to instantly trace a cable from end to end without complex testers. These cables are ideal for use in new copper network installations for a guaranteed reduction in downtime when dealing with faulty wiring and wiring mistakes. The EVO6™ is made of quality copper, and covered in a thick PVC jacket for maximum longevity.

Images

For custom quantities or lengths, please call us at 866-222-0030

PART # LENGTH QUANTITY / PACK COLOR
View the Colors
WEIGHT / PACK PRICE
CAT6 (UTP)
MTK-EVO6U-03 3 ft (0.91 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 0.93 lb [420g]
Qty:
MTK-EVO6U-05 5 ft (1.52 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 1.54 lbs [700g]
Qty:
MTK-EVO6U-06 6 ft (1.82 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 1.85 lbs [840g]
Qty:
MTK-EVO6U-07 7 ft (2.13 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 2.16 lbs [980g]
Qty:
MTK-EVO6U-10 10 ft (3.04 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 3.09 lbs [1400g]
Qty:
MTK-EVO6U-15 15 ft (4.57 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 4.63 lbs [2100g]
Qty:
MTK-EVO6U-16 16 ft (4.87 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 4.94 lbs [2240g]
Qty:
MTK-EVO6U-20 20 ft (6.09 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 6.17 lbs [2800g]
Qty:
MTK-EVO6U-25 25 ft (7.62 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 3.86 lbs [1750g]
Qty:
MTK-EVO6U-50 50 ft (15.24 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 7.72 lbs [3500g]
Qty:
MTK-EVO6U-100 100 ft (30.48 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 15.43 lbs [7000g]
Qty:

CAT6A (FTP)
MTK-EVO6F-03 3 ft (0.91 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 0.93 lb [420g]
Qty:
MTK-EVO6F-05 5 ft (1.52 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 1.54 lbs [700g]
Qty:
MTK-EVO6F-06 6 ft (1.82 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 1.85 lbs [840g]
Qty:
MTK-EVO6F-07 7 ft (2.13 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 2.16 lbs [980g]
Qty:
MTK-EVO6F-10 10 ft (3.04 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 3.09 lbs [1400g]
Qty:
MTK-EVO6F-15 15 ft (4.57 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 4.63 lbs [2100g]
Qty:
MTK-EVO6F-16 16 ft (4.87 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 4.94 lbs [2240g]
Qty:
MTK-EVO6F-20 20 ft (6.09 m) 10 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 6.17 lbs [2800g]
Qty:
MTK-EVO6F-25 25 ft (7.62 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 3.86 lbs [1750g]
Qty:
MTK-EVO6F-50 50 ft (15.24 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 7.72 lbs [3500g]
Qty:
MTK-EVO6F-100 100 ft (30.48 m) 5 Black, Blue, Green, Gray, Orange, Purple, Red, White, Yellow 15.43 lbs [7000g]
Qty:
  • Bright red flashing LED light allows you to trace cables even in the darkest IT closets, ensuring easy use in any application
  • Supports 10Mbps, 100Mbps, and Gigabit Ethernet for nearly future-proof performance
  • Snag-free boot provides strain relief and prolongs the life of both the cable and the connections on your network components
  • FT4 rated with maximum temperature of 167° F (75° C) for use in warmer environments
  • Widely available replacement CR927 Lithium (included) battery allows quick and cost-effective cable maintenance
  • Supports proper cable management by allowing you to keep connections intact during maintenance
  • Facilitates maintenance in medium to high-density network installations, especially over long distance and hidden runs
PROPERTY VALUE
Performance Standard Category 6
Wire 4 pair 24 AWG, 1 pair 30 AWG
Jacket Material PVC
Plug Material Clear Polycarbonate
Plug Contacts Copper Alloy with 50 micro inch gold plating
Life Expectancy 750 Plug Insertions
Maximum Operating Temperature 167°F (75°C)
Battery CR927 Lithium (included) with 1000 button press life expectancy and 10 year shelf life
Industry Standards TIA/EIA-568-B.2-1
UL 94 V-0
FCC Part 68
IEC 60603-7
ISO 9001
RoHS Compliant
CE Certified

No Manuals Available
