Leviton 10/100 Mbps 4-Port Internet Gateway
This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player
|
|
- Built-in NAT firewall keeps your network and communications secure from outside observation
- Designed to be used with Leviton Structured Media™ enclosures or as a standalone unit
- The easy to use built-in DHCP server allows you to control what comes in and what goes out, as well as the setup and allocation of IP addresses in your local area network
- Soft glow LED indicator lights displays the gateway's power, status, Link/Activity, 100 Mbps, and WAN,
- Installation is easy: gateway connects to modems and/or switches using standard CAT 5 or CAT 5E patch cords
- Customize your web access and block any unwanted sites with the new URL blocking feature
- Features UPnP (Universal Plug-and-Play) that automatically discovers and configures your gateway to be compatible with Windows® ME®, XP®, or later operating systems
- 2 year limited manufacturer warranty
Leviton 10/100 Mbps 4-Port Internet Gateway for high-speed broadband connections is the fast and easy way to keep your home, office, or educational facility connected and secured against outside influences. This gateway comes complete with a mounting bracket that easily installs into any Leviton Structured Media enclosure, which acts as a center point for your network and other home or business media applications.
Additional Product Information -
| Mechanical Specifications | |
| LAN Interface: | 4 RJ-45 Connector 10/100Mbps ports |
| WAN Interface: | 1 RJ-45 Connector port for DSL or Cable Modem Connection |
| Uplink Ports | 1 |
| AC Power Adapter: | Yes |
| Reset Button: | Resets to factory default settings or restarts unit |
| LED indicators | One power indicator, one status indicator, four Link/Activity indicators, four 100Mbps indicators, and one WAN indicator |
| Cabling Requirements: | Standard Cat5/5e UTP |
| Security: | NAT Firewall. Password-protected configuration. Stateful Packet Inspection |
| Management: | WEB GUI configuration |
| Operating System: | Windows ME, XP, or later |
| Electrical Ratings | |
| Power Supply: | 12VDC @ 800mA |
| Performance Data | |
| Network protocols: | TCP/IP, DHCP, ICMP, DNS, NAT, TFTP, HTTP, PPPoE |
| FCC: | Part 15 |
| Speed: | 10/100 Base-T/TX |
| Firewall: | NAT-Network Address Translation |
| Temperature | |
| Operating Temperature: | 32°F to 104°F (0° C to 40° C) |
| Storage Temperature: | 18°F to 158°F (-10° C to 70° C) |
| Standards and Certifications | |
| IEEE 802.3 | 10 Base-T Ethernet |
| IEEE 802.3u | 100 Base-TX Fast Ethernet |
| FCC | 15 Class B |
| Warranty: | 2 year limited manufacturer warranty |
| PART # | DESCRIPTION | DIMENSIONS | WEIGHT | PRICE |
| LE-47611-GT4 | Leviton 10/100 Mbps 4 Port Internet Gateway | 2.5”H x 6.5”W x 3.27”D | 2.13 lbs |
