2.1 Heat Shrink Tubing – Professional Grade Insulation and Flame Resistance

Home > Heat Shrink > 2:1 Heat Shrink Tubing > 2:1 Heat Shrink

2:1 Heat Shrink Tubing
Professional Grade Flexible Flame Retardant Polyolefin

Insulate, Seal and Protect Hoses, Braided Sleeving and Cable Splices

view more images

CableOrganizer Image/Video Popup Viewer Close Window

2:1 Heat Shrink Tubing Professional Grade Flexible Flame Retardant Polyolefin

Videos

Additional Images

This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player
Copyright ©2012 CableOrganizer.com

View Colors

What's special about this heat shrink tubing?

High performance 2:1 heat shrink material secures, bundles, and protects cables, wire and hoses
Superior quality designed for government/military, industrial and commercial applications
UL Listed and VW1 Flame Tested to resist high temperatures, chemicals and oils for ultimate protection

This high performance, multi purpose polyolefin based, heat shrinkable tubing meets/exceeds all specifications for electrical, chemical and physical properties. It is designed for a wide range of applications, including military and commercial, and for the consumer/OEM market requiring Underwriters Laboratories and/or Canadian Standards approval. It is used extensively for cable and wire harnessing, strain relief, insulation, color-coding, identification and protection

Price
Features
Specifications
Manuals
Reviews
Related Items

Available in 17 sizes to securely cover a variety of applications, such as terminating the ends of braided sleeving, or neatly bundling a group of cables together
Chose from 12 colors for color coding wiring, or to match the cable jacket when protecting a splice
Meets or exceeds all Military specifications for a reliable quality installation
LG heat shrinkable and non-shrinkable tubing products do not contain the compound Di (2-ethylhexyl) phthalate commonly referred to as DEHP
In addition, LG heat shrinkable and non-shrinkable tubing products do not contain PFOS (perfluoroctane sulfonate), PFOA (perfluorocanoic acid) or Tinuvin 320

Due to the nature of heat shrink, it does shrink length wise as well as the diameter 2:1 heat shrink will shrink 7% or less in the axial direction during the shrink process

UV Reactive or Glow in the Dark Heat Shrink
We now stock PVC heat shrink, in bright highly UV reactive neon colors. It is available in a 2:1 shrink ratio, and three sizes (1/4", 3/8", 1/2"). Colors currently available are Luminous Pink, Neon Pink, Neon Yellow, Neon Green, Luminous Green, and Gold. For more information and pricing, click here.

This product has starred in our Product Showcase Blog! Click here to check it out.

Adhesive Lined Tubing

Our 2:1 heat shrink tubing is also available with a “dual-wall” construction. During application, the inner layer melts and flows, creating an adhesion layer to ensure a snug fit to your harness and/or connector. It is also recommended for applications that require a water-tight seal to protect wire, cable and connector components.

2:1 Dual Wall requires a 100 FT Minimum Purchase. Please Call 1-866-222-0030

For Technical Specifications, click here

For orders less than 100 FT, Click here to see our 3:1 Dual Wall

Expanded as supplied
heat shrink tubing diagram
Fully recovered after heating

SIZE	Internal Diameter Minimum (D)		Internal Diameter Maximum (d)		Minimum Total Wall Thickness (t)		Standard Spool Length
SIZE	In.	mm	In.	mm	In.	mm	ft
3/64"	0.055	1.4	0.022	0.58	0.013	0.33	500
1/16"	0.075	1.9	0.031	0.79	0.014	0.356	500
3/32"	0.11	2.8	0.046	1.17	0.017	0.432	500
1/8"	0.138	3.5	0.062	1.57	0.017	0.432	500
3/16"	0.2	5	0.093	2.36	0.017	0.432	250
1/4"	0.256	6.5	0.125	3.18	0.022	0.559	250
3/8"	0.38	9.6	0.187	4.75	0.022	0.559	200
1/2"	0.5	12.8	0.25	6.35	0.022	0.559	200
3/4"	0.76	19.3	0.37	9.35	0.027	0.686	100
1"	1.02	25.7	0.5	12.7	0.03	0.762	100
1-1/4"	1.26	32.2	0.63	16	0.034	0.864	100
1-1/2"	1.5	38.1	0.586	14.9	0.034	0.864	100
2"	2"	51	1	25.4	0.038	0.965	100
3"	3"	76.2	1.5	38.1	0.042	1.07	100
4"	4"	102	2	50.8	0.046	1.17	100

2:1 Heat Shrink Tubing Technical Specifications

Physical
PROPRIETARY	TEST METHOD	TYPICAL VALUE
Tensile Strength	ASTM D 638	13 N/mm²
Elongation at Break	ASTM D 638	400%
Longitudinal Change	ASTM D 2671	+5%,-5% maximum
Water Absorption	ASTM D 570	0.15% Maximum
Specific Gravity	ASTM D 792	1.4
Electrical
Dielectric Strength	ASTM D 2671	25kV/mm
Volume Resistivity	ASTM D 257	10@ 14 ohm.cm
Chemical
Fungus Resistance	MIL-I-7444	Inert
Fluid Resistance	MIL-I-23053/5	Good
Cooper Corrosion	ASTM D 2671 B	Good
Thermal
Continuous Operating Temperature		-55°C to +135VC
Minimum Shrink Temperature		>90°C
Heat Shock 4 hours at 250°C	ASTM D 2671	No dripping, cracking or flowing
Heat Aging 168 hours at 150°C	ASTM D 638	Elongation 300%
Low Temperature Flexibility -55°C	ASTM D 2671C	No cracking
Flammability	UL 224 VWI	Pass (colors only)

*Clear Tubing is not Flame Retardant

Specification reference:
UL 224 125°C, 600V, VW-1
CSA-C22.2 No. 198-M1986 125°C, 600V
File LR33298 Guide 400-U-9

2:1 Heat Shrink - PER FOOT AND PER SPOOL

Please Note: Our Diameters for Heat Shrink Tubing are measured as ROUND TUBE, NOT FLAT
Due to the nature of the materials, all braided sleeving, wire loom, heat shrink, and spiral wrap products sold by the foot will not be refunded IN FULL if they are cut up in sections of 20' or shorter.
50% restocking fee on returns of 20 feet or less. 25% restocking fee if there is a reorder.

Please call us for availability of colors in diameters greater than 1 inch

PART #	NOMINAL SIZE		COLOR View Samples Below	QTY DISCOUNT		PRICE/ FOOT
	Before	After		LENGTH	PRICE/FOOT
Pricing is automatically calculated based on quantity entered at checkout
HS2-0047FT	3/64"	285"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-99 ft	$0.50 per ft	$0.50 Qty:
				100+ ft	$0.32 per ft
HS2-0063FT	1/16"	1/32"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown	1-99 ft	$0.53 per ft	$0.53 Qty:
				100+ ft	$0.35 per ft
HS2-0094FT	3/32"	15/32"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-99 ft	$0.58 per ft	$0.58 Qty:
				100+ ft	$0.37 per ft
HS2-0125FT	1/8"	1/16"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Yellow/Green	1-99 ft	$0.68 per ft	$0.68 Qty:
				100+ ft	$0.44 per ft
HS2-0188FT	3/16"	3/32"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$0.83 per ft	$0.83 Qty:
				50+ ft	$0.54 per ft
HS2-025FT	1/4"	1/8"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$0.90 per ft	$0.90 Qty:
				50+ ft	$0.58 per ft
HS2-0375FT	3/8"	3/16"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$0.96 per ft	$0.96 Qty:
				50+ ft	$0.61 per ft
HS2-050FT	1/2"	1/4"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$1.03 per ft	$1.03 Qty:
				50+ ft	$0.67 per ft
HS2-0625FT	5/8"	5/16"	Black, Brown, Clear, White, Purple	1-49 ft	$1.35 per ft	$1.35 Qty:
				50+ ft	$0.94 per ft
HS2-075FT	3/4"	3/8"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$1.58 per ft	$1.58 Qty:
				50+ ft	$1.02 per ft
HS2-0875FT	7/8"	7/16"	White, Blue, Green, Purple	1-49 ft	$1.71 per ft	$1.71 Qty:
				50+ ft	$1.11 per ft
HS2-100FT	1"	1/2"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	1-49 ft	$2.00 per ft	$2.00 Qty:
				50+ ft	$1.30 per ft
HS2-125FT	1-1/4"	5/8"	Black, Clear, Yellow, White, Brown, Yellow/Green	1-49 ft	$2.59 per ft	$2.59 Qty:
				50+ ft	$1.68 per ft
HS2-150FT	1-1/2"	3/4"	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Brown, Yellow/Green	1-49 ft	$3.85 per ft	$3.85 Qty:
				50+ ft	$2.50 per ft
HS2-200FT	2"	1"	Black, Orange, Clear, Yellow, White, Red, Blue, Green	1-49 ft	$4.25 per ft	$4.25 Qty:
				50+ ft	$2.76 per ft
HS2-300FT	3"	1-1/2"	Black, Orange, Clear, Yellow, White	1-24 ft	$7.00 per ft	$7.00 Qty:
				25+ ft	$4.55 per ft
HS2-400FT	4"	2"	Black, Orange, Clear, Yellow, Yellow/Green	1-24 ft	$9.40 per ft	$9.40 Qty:
				25+ ft	$6.11 per ft

Bulk Spools

PART #	SIZE		SPOOL LENGTH	COLOR View Samples Below	PRICE
PART #	Before	After	SPOOL LENGTH	COLOR View Samples Below	PRICE
HS2-0047SP500	3/64"	2/85"	500 ft	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	$96.53 Qty:
HS2-0063SP500	1/16"	1/32"	500 ft		$103.74 Qty:
HS2-0094SP500	3/32"	15/32"	500 ft		$112.32 Qty:
HS2-0125SP500	1/8"	1/16"	500 ft		$133.38 Qty:
HS2-0188SP250	3/16"	3/32"	250 ft		$67.56 Qty:
HS2-025SP250	1/4"	1/8"	250 ft		$87.36 Qty:
HS2-0375SP200	3/8"	3/16"	200 ft		$93.60 Qty:
HS2-050SP200	1/2"	1/4"	200 ft		$80.50 Qty:
HS2-0625SP200	5/8"	5/16"	200 ft	Black, Clear	$105.30 Qty:
HS2-075SP100	3/4"	3/8"	100 ft	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Gray, Purple, Brown, Yellow/Green	$82.85 Qty:
HS2-100SP100	1"	1/2"	100 ft		$77.81 Qty:
HS2-125SP100	1-1/4"	5/8"	100 ft	Black, Clear, Yellow, White, Blue, Yellow/Green	$101.01 Qty:
HS2-150SP100	1-1/2"	3/4"	100 ft	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Brown, Yellow/Green	$150.15 Qty:
HS2-200SP100	2"	1"	100 ft	Black, Orange, Clear, Yellow, White, Red, Blue, Green, Yellow/Green	$165.75 Qty:
HS2-300SP100	3"	1-1/2"	100 ft	Black, Orange, Clear, Yellow, White, Yellow/Green	$273.00 Qty:
HS2-400SP100	4"	2"	100 ft	Black, Orange, Clear, Yellow, Yellow/Green	$366.60 Qty:

2:1 Thin Wall Heat Shrink
HS2-100FT-THIN	1"	1/2"	100 ft	Black	$2.10 Qty:

Normally our policy is to supply continuous lengths. If it is absolutely necessary to receive one continuous length, please specify.
