Wall-Mountable Connector Housings (WCH)



Corning Wall-Mountable Connector Housing

More Images
Close Window

Wall-Mountable Connector Housings (WCH)

    Additional Images
  • Wall-Mountable Connector Housing holds up to 4 connector panels - icon
  • Wall-Mountable Connector Housing holds up to 6 connector panels - icon
  • Wall-Mountable Connector Housing holds up to 12 connector panels - icon

This requires one or more of the following: javascript enabled, Flash Video Player, and Quicktime or Windows Media Player
Copyright ©2013 CableOrganizer.com



Low Price GuaranteeWhat's special about this connector housing from Corning?

  • Optimized design for field connectorization
  • Suitable for loose tube and tight-buffered fiber optic cables
  • Metal cabinet construction
  • Jumper routing guides and jumper strain-relief point
  • Optional field-installable lock kit
  • Includes bracket for buffer tube fan-out kits
  • Click for More Features

Corning Wall-Mountable Connector Housings (WCH) optimized design provides your network with interconnections or cross-connections capabilities between optoelectronics and outside-plant, riser and distribution cables. Their durable clear, tinted doors allow for easy viewing of jumper connections. These units are available in two, four, six and twelve-panel configurations, and can be wall-mounted in telecommunications rooms and main cross-connects.

  • Optimized design for field connectorization
  • Suitable for loose tube and tight-buffered fiber optic cables
  • Metal cabinet construction
  • Jumper routing guides and jumper strain-relief point
  • Optional field-installable lock kit
  • Includes bracket for buffer tube fan-out kits
  • Optional splice tray holder allows easy cable routing and is designed to make field splicing easier; splice trays ordered separately
  • Accepts standard CCH connector panels
  • -04P, -06P and -12P housing have a durable, clear polycarbonate-tinted jumper door for easy viewing of jumper connections



NOTE: Only compatible with Corning adapter panels

PART # DESCRIPTION DIMENSIONS WEIGHT PRICE
IT-WCH-02P Wall-Mountable Connector Housing, 24 fiber total capacity, any connector type, Panel capacity up to 2, Family name: LANscape 9.25" H x 13.06" W x 3.25" D 5.4 lbs
$105.26 Qty:
IT-WCH-04P Wall-Mountable Connector Housing, 48 fiber total capacity, any connector type, Panel capacity up to 4, Family name: LANscape 13.5" H x 16.06" W x 4.06" D 6.2 lbs
$163.43 Qty:
IT-WCH-06P Wall-Mountable Connector Housing, 72 fiber total capacity, any connector type, Panel capacity up to 6, Family name: LANscape 13.5" H x 16.06" W x 5.125" D 7.2 lbs
$258.75 Qty:
IT-WCH-12P Wall-Mountable Connector Housing, 144 fiber total capacity, any connector type, Panel capacity up to 12, Family name: LANscape 13.5" H x 22.50" W x 5.125" D 9 lbs
$374.25 Qty:

ships in 1-2 weeks



Accessories

PART # DESCRIPTION PRICE
CN-WJG-02R Wall Mountable Jumper Storage Guides
That provide jumper management; kit includes two routing guides and mounting screws
$58.32 Qty:
CN-WCH-STDOFF-BKT Wall-Mountable Connector Housing Wall
Stand-off brackets for 04P, 06P, 08P and 12P; brackets provide a 1" spacing wall
$47.09 Qty:
CN-WCH-STDOFF-BKT-2P Wall -Mountable Connector Housing Wall
Stand-off brackets for 02P; brackets provide a 1" spacing wall
$24.64 Qty:
CN-BKT-ALL-R23-75 Universal Rack-Mount Bracket for 19" or 23" equipment racks; allows for rack mounting of the wall-mountable units
$90.11 Qty:
CN-WCH-STRNRLF-KCN Optional External Cable Strain-Relief Kit
that utilizes Corning Cable System's. Universal cable clamp ; includes bracket, mounting hardware, one strain-relief clamp and one multi-cable insert that will hold up to five cables less than .4 inches in diameter
$26.42 Qty:
CN-WCH-DUST-CVR Optional Dust Cover for 04P and 08P housing;
covers jumper exits; includes two covers and mounting hardware
$32.54 Qty:
CN-WCH-DUST-CVR-D Optional Dust Cover for 06P and 12P housing;
covers two jumper exits; includes two covers and mounting hardware; two kits required for 12P
$46.71 Qty:
CN-WCH-LBL-KCN Replacement label for WCH
$7.02 Qty:
CN-HDWR-LOCK-KCN Lock kit for front door of housing;
contains one lock with two keys
$24.56 Qty:
CN-WCH-SPLC-12 Splice Tray Holder for WCH-12P;
Accommodates twelve 0.2" thick (type 2R) or six 0.4" thick (type 4R) reduced length splice trays (splice trays are ordered separately)
$53.73 Qty:
CN-WCH-SPLC-4-8 Splice Tray Holder for WCH-04P, WCH-06P, WCH-08P
Accommodates eight 0.2" thick (type 2R) or four 0.4" thick (type 4R) reduced length splice trays (splice trays are ordered separately)
$35.98 Qty:
CN-WCH-SPLC-2P Splice Tray Holder for WCH-02P;
Accommodates two 0.2" thick (type 2R) or two 0.4" thick (type 4R) reduced length splice trays (splice trays are ordered separately)
$15.19 Qty:
CN-WCH-SSH-2 Wall-Mountable Slack Storage Housing for WCH-02P;
Accommodates four 0.2" thick (type 2R) or two 0.4" thick (type 4R) reduced length splice trays
$110.36 Qty:
CN-WCH-SSH-4-12 Wall-Mountable Slack Storage Housing for WCH-04P, WCH-06P, WCH-08P and WCH-12P;
Accommodates eight 0.2" thick (type 2R and 2S) or four 0.4" thick (type 4R and type 4S) standard or reduced-length splice trays or four UST splice trays
$136.35 Qty:
