Corning FREEDM Ribbon Riser Cables

Corning FREEDM® Ribbon Riser Cables



Low Price Guarantee

CN-024SC7-14180-20

What is special about Ribbon Riser Cable?

  • OFNR/FT-4 listed
  • Available in 50 μm and 62.5 μm varieties
  • Singles-mode and hybrid versions available
  • 12-fiber ribbons are easily identifiable, with ribbon ID members and distinct fiber colors
  • Click for More Features

With fiber counts ranging from 12 to 216, Corning Cables Systems Ribbon Riser Cables are made up of easy to identify 12-fiber ribbons, which are all held together within a central tube. These optical fiber cables have dielectric strength members for excellent tensile strength, and feature flame-retardant outer jackets, which have been manufactured in accordance with UL 1666 flame test requirements.

  • layers of corning ribbon riser cable icon
  • crossection diagram of 72-fiber corning ribbon riser cable icon
  • crossection diagram of 216-fiber corning ribbon riser cable icon

Images

  • layers of corning ribbon riser cable icon
  • crossection diagram of 72-fiber corning ribbon riser cable icon
  • crossection diagram of 216-fiber corning ribbon riser cable icon

There is a 2,624 FT minimum for the 24, 48, 72, 144 and 216 fibers ribbon cables. The minimum quantity for the 36 fibers ribbon cable is 5,248 FT.
These products ship within 3-4 weeks

PART # DESCRIPTION MINIMUM QUANTITY PRICE/FT TOTAL PRICE
CN-024SC7-14180-20 24 Fiber Ribbon Cable Riser, 50UM 10GBE 2,624 FT $6.54
Qty:
CN-036SC7-14180-20 36 Fiber Ribbon Cable Riser, 50UM 10GBE 5,248 FT $9.15
Qty:
CN-048SC7-14180-20 48 Fiber Ribbon Cable Riser, 50UM 10GBE 2,624 FT $11.66
Qty:
CN-072SC7-14180-20 72 Fiber Ribbon Cable Riser, 50UM 10GBE 2,624 FT $16.45
Qty:
CN-144SC7-14180-20 144 Fiber Ribbon Cable Riser, 50UM 10GBE 2,624 FT $31.14
Qty:
CN-216SC7-14180-20 216 Fiber Ribbon Cable Riser, 50UM 10GBE 2,624 FT $45.70
Qty:
  • Individual fibers are easily accessible
  • Excellent mass splicing yields, thanks to precise fiber and ribbon geometries
  • Also available preconnectorized, to reduce labor costs and simplify field installation
  • Can be used with standard ribbon cable hardware and procedures
  • 10 Gigabit Ethernet capabilities



Ribbon Riser Cable

Click here to view Specifications and Transmission Performance (PDF) PDF
